The BL1117-1.5 is a low dropout (LDO) positive voltage regulator produced by SHANGHAI BELLING CO., LTD. This regulator is designed to provide a stable and accurate 1.5V output voltage from a higher input voltage. It is commonly used in a variety of electronic devices to ensure a consistent power supply for sensitive components.

Applications:

• Microcontroller power supplies: Providing a stable 1.5V supply for microcontrollers and other digital logic devices.
• Post-regulation for switching regulators: Improving the output ripple and noise performance of switching power supplies.
• Battery-powered devices: Regulating the voltage from a battery to ensure consistent performance as the battery discharges.
• Linear regulators for noise-sensitive applications: Providing a clean and stable voltage source in audio equipment, sensors, and RF circuits.
• Power management in portable devices: Used in devices such as smartphones, tablets, and portable media players.

Features:

• Low Dropout Voltage: The BL1117-1.5 features a low dropout voltage, meaning it can maintain regulation even when the input voltage is only slightly higher than the output voltage.
• Fixed Output Voltage: Provides a fixed 1.5V output, ensuring a stable power supply.
• Overcurrent Protection: Includes overcurrent protection to prevent damage from excessive current draw.
• Thermal Overload Protection: Incorporates thermal overload protection, shutting down the regulator if it overheats.
• High Accuracy: Offers high output voltage accuracy, ensuring reliable performance.

Benefits:

• Stable Power Supply: Provides a stable and accurate 1.5V output, ensuring reliable operation of connected components.
• Protection Against Damage: Overcurrent and thermal overload protection prevent damage to the regulator and connected circuitry.
• Efficient Operation: Low dropout voltage allows for efficient operation, especially in battery-powered devices.
• Easy to Use: Simple design with minimal external components required.
• Compact Size: Small footprint allows for integration into space-constrained applications.

Additional Details:

The BL1117-1.5 typically requires only a few external components, such as input and output capacitors, for stable operation. The datasheet provides detailed information on recommended capacitor values and layout guidelines. The regulator is available in various surface-mount packages. The operating temperature range is typically from -40°C to +125°C. It is important to consult the datasheet for the specific operating conditions and limitations of the device.
