ESD5Z5V

Part No ESD5Z5V
Manufacturer Shanghai Semitech Semiconductor Co., Ltd
Catalog END - OF - LIFE
Description Unidirectional Configurations
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Shanghai Semitech Semiconductor Co., Ltd
Win Source Part Number 1172659-ESD5Z5V
Manufacturer Homepage www.semitech.cn
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian ESD5Z5V CAD Model

Description

The ESD5Z5V is an ESD protection diode manufactured by Shanghai Semitech Semiconductor Co., Ltd. It's designed to safeguard sensitive electronic components from electrostatic discharge (ESD) damage. This diode is specifically engineered to provide a low clamping voltage, which is critical in protecting modern, low-voltage circuitry found in various consumer electronics and industrial applications.

Applications

  • Smartphones: Protection of I/O ports, USB interfaces, and audio lines from ESD.
  • Tablets: Guarding LCD screens, touchscreens, and charging ports against ESD strikes.
  • Laptops: Safeguarding USB ports, HDMI ports, and other external interfaces.
  • Wearable Devices: Protection for smartwatches, fitness trackers, and Bluetooth headsets.
  • Set-Top Boxes: Preventing ESD damage to HDMI ports and Ethernet interfaces.
  • Digital Cameras: ESD protection for memory card slots, USB ports, and display interfaces.

Features

  • Low Clamping Voltage: Provides excellent protection by limiting the voltage surge during an ESD event.
  • Low Capacitance: Ensures minimal signal distortion in high-speed data lines.
  • ESD Protection: Meets and exceeds industry standards for ESD immunity, ensuring device reliability.
  • Small Package Size: Allows for easy integration into space-constrained applications.
  • Fast Response Time: Quickly clamps transient voltages, minimizing stress on protected components.
  • RoHS Compliant: Environmentally friendly, adhering to Restriction of Hazardous Substances directives.

Benefits

  • Increased Device Reliability: Reduces the risk of ESD-related failures, extending the lifespan of electronic devices.
  • Improved Signal Integrity: Low capacitance ensures clean signal transmission, preventing data errors.
  • Lower Warranty Costs: Minimizes the likelihood of field failures due to ESD damage, reducing support expenses.
  • Compact Design: Small footprint allows for efficient use of PCB space.
  • Enhanced Protection: Provides robust protection against ESD strikes exceeding industry standards.
  • Environmentally Responsible: RoHS compliance ensures the product is free from harmful substances.

Additional Details

The ESD5Z5V is designed to meet IEC 61000-4-2 standards for ESD immunity. Its low clamping voltage is crucial for protecting sensitive components operating at low voltages. The device typically comes in a SOD-523 package. The clamping voltage is approximately 7V at an 8A surge current (tp=8/20μs). Its low capacitance (typically around 0.5pF) makes it ideal for protecting high-speed data lines such as USB 2.0. The operating junction temperature range is -55°C to +150°C. It's well-suited for applications where space is a premium, and robust ESD protection is essential.
