SI8631ED-B-ISR Real Image SI8631ED-B-ISR Real Image
Same model may have multiple batches, images only for reference.
SI8631ED-B-ISR Real Image SI8631ED-B-ISR Real Image
SI8631ED-B-ISR Real Image SI8631ED-B-ISR Real Image
Same model may have multiple batches, images only for reference.

SI8631ED-B-ISR

Part No SI8631ED-B-ISR
Manufacturer Skyworks Solutions Inc.
Catalog Digital Isolators
Description DGTL ISO 5000VRMS 3CH GP 16SOIC
Datasheet
SI8631ED-B-ISR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Isolators - Digital Isolators
Mfr Skyworks Solutions Inc.
Package Tape & Reel
Product Status Active
Technology Capacitive Coupling
Type General Purpose
Isolated Power No
Number of Channels 3
Inputs - Side 1/Side 2 2/1
Channel Type Unidirectional
Voltage - Isolation 5000Vrms
Common Mode Transient Immunity (Min) 35kV/µs
Data Rate 150Mbps
Propagation Delay tpLH / tpHL (Max) 13ns, 13ns
Pulse Width Distortion (Max) 4.5ns
Rise / Fall Time (Typ) 2.5ns, 2.5ns
Voltage - Supply 2.5V ~ 5.5V
Temperature Range - Operating -40°C ~ 125°C
Mounting Type Surface Mount
Package / Case 16-SOIC (0.295", 7.50mm Width)
Supplier Device Package 16-SOIC
Base Product Number SI8631
Standard Package 1,250 pcs
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 852792-SI8631ED-B-ISR
Ultra Librarian 3D Model Ultra Librarian SI8631ED-B-ISR CAD Model

Description

The SI8631ED-B-ISR is a digital isolator from Skyworks Solutions Inc.

  • Product Name: SI8631ED-B-ISR
  • Manufacturer: Skyworks Solutions Inc.
  • Category: Isolators - Digital Isolators
  • Application: General Purpose
  • Package: Tape & Reel
  • Standard Package Size: 1,250 pieces
  • Technology: Capacitive Coupling
  • Data Rate: 150Mbps
  • Direction: Unidirectional
  • Rise/Fall Time: 2.5ns
  • Channels: 3
  • Voltage Isolation: 5000Vrms
  • Inputs: Side 1 and Side 2
  • Common Mode Transient Immunity: 35kV/μs
  • Propagation Delay (tpLH/tpHL): 13ns
  • Pulse Width Distortion: 4.5ns
  • Isolated Power: No
  • Voltage Supply: 2.5V to 5.5V
  • Mounting Type: Surface Mount
  • Package / Case: 16-SOIC
