The SKY13352-337LF-EVB is an evaluation board designed to assess the performance of the SKY13352-337LF, a Single-Pole, Double-Throw (SPDT) switch. This evaluation board enables engineers and designers to test and validate the switch's functionality in various RF applications.

Applications

• Testing and evaluation of RF switch performance
• Prototyping and development of RF circuits
• Verification of switch parameters such as insertion loss, isolation, and return loss
• Educational purposes for understanding RF switch characteristics

Features

• On-board SMA connectors for easy connection to test equipment
• Clearly labeled test points for performance measurements
• Comprehensive documentation including schematic and bill of materials
• Optimized layout for accurate and repeatable measurements
• Facilitates quick evaluation of the SKY13352-337LF switch

Benefits

• Accelerates the design and development process by providing a ready-to-use test platform
• Reduces the risk of design errors by allowing thorough testing before integration
• Improves time-to-market by simplifying the evaluation process
• Provides accurate and reliable performance data for the SKY13352-337LF switch

Additional Details

The SKY13352-337LF is a broadband SPDT switch designed for various applications. The evaluation board allows users to measure key performance metrics such as insertion loss, isolation, return loss, and switching speed. The board includes SMA connectors for input and output signals, as well as test points for DC bias and control signals. Proper impedance matching and layout techniques are employed to minimize signal reflections and ensure accurate measurements.
