Same model may have multiple batches, images only for reference.

SI8641ED-B-IS2

Name: SI8641ED-B-IS2
Brand: Skyworks Solutions Inc.
SKU: 1243873
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	SI8641ED-B-IS2
Manufacturer	Skyworks Solutions Inc.
Catalog	Digital Isolators
Description	DGTL ISO 5000VRMS 4CH GP 16SOIC / General Purpose Digital Isolator 5000Vrms 4 Channel 150Mbps 50kV/µs CMTI 16-SOIC (0.295", 7.50mm Width)
Datasheet	SI8641ED-B-IS2 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Isolators>Digital Isolators
Mfr	Skyworks Solutions Inc.
Series	Si864x
Package	Tube
Technology	Capacitive Coupling
Type	General Purpose
Isolated Power	No
Number of Channels	4
Inputs - Side 1/Side 2	3/1
Channel Type	Unidirectional
Voltage - Isolation	5000Vrms
Common Mode Transient Immunity (Min)	50kV/µs
Data Rate	150Mbps
Propagation Delay tpLH / tpHL (Max)	13ns, 13ns
Pulse Width Distortion (Max)	4.5ns
Rise / Fall Time (Typ)	4ns, 4ns
Voltage - Supply	2.5V ~ 5.5V
Temperature Range - Operating	-40°C ~ 125°C
Mounting	SMD (SMT)
Package / Case	16-SOIC (0.295", 7.50mm Width)
Supplier Device Package	16-SOIC
Base Product Number	SI8641
Other Names	336-4215
Standard Package	46
MSL Level	3 (168 Hours)
ECCN	EAR99
HTSUS	8542.39.0001
Win Source Part Number	1243873-SI8641ED-B-IS2
Ultra Librarian 3D Model	Ultra Librarian SI8641ED-B-IS2 CAD Model

Alternative Products

Description

The SI8641ED-B-IS2 is a 4-channel unidirectional digital isolator that is part of the Si864x series from Skyworks Solutions Inc.

Data Rate: 150Mbps
Operating Temperature Range: -40°C to 125°C
Common Mode Transient Immunity: 50kV/µs
Propagation Delay: 13ns
Mounting: SMD (SMT)
Package: 16-SOIC package with a width of 0.295 inches
Application: digital isolator applications.
