CESD12VD5 Jiangsu Changjiang Electronics Technology Co., Ltd CESD12VD5 Real Image
Same model may have multiple batches, images only for reference.
CESD12VD5 Jiangsu Changjiang Electronics Technology Co., Ltd CESD12VD5 Real Image
CESD12VD5 Jiangsu Changjiang Electronics Technology Co., Ltd CESD12VD5 Real Image
Same model may have multiple batches, images only for reference.

CESD12VD5

Part No CESD12VD5
Manufacturer SMC Diode Solutions
Catalog TVS - Diodes
Description 12V TVS,PACKAGE SOD-523, TVS ARR
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Circuit Protection - Transient Voltage Suppressors (TVS) - TVS Diodes
Mfr SMC Diode Solutions
Package Tape & Reel (TR)Cut Tape (CT)
Product Status Active
Type Zener
Unidirectional Channels 1
Voltage - Reverse Standoff (Typ) 12V (Max)
Voltage - Breakdown (Min) 14.1V
Voltage - Clamping (Max) @ Ipp 24V
Current - Peak Pulse (10/1000µs) 9A
Power - Peak Pulse 220W
Power Line Protection No
Applications General Purpose
Capacitance @ Frequency 45pF @ 1MHz
Temperature Range - Operating -55°C ~ 150°C (TJ)
Mounting Type Surface Mount
Package / Case SC-79, SOD-523
Supplier Device Package SOD-523
Standard Package 8,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Affected
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 578557-CESD12VD5
Ultra Librarian 3D Model Ultra Librarian CESD12VD5 CAD Model

Description

The 578557-CESD12VD5 is a Zener type TVS diode designed for general-purpose circuit protection.

  • Package: tape & reel (TR) or cut tape (CT)
  • Standard Package: 8,000 pieces
  • Channel: unidirectional
  • Voltage Reverse Standoff (max): 12V
  • Voltage Breakdown: 14.1V
  • Voltage Clamping @ Ipp: 24V
  • Power Peak Pulse: 220W
  • Capacitance @ 1MHz: 45pF
  • Current Peak Pulse: 9A for a duration of 10/1000µs
  • Manufacturer: SMC Diode Solutions
  • Mounting: surface mountable
  • Operating Temperature: -55°C to 150°C (TJ)
  • Status: active product
