Same model may have multiple batches, images only for reference.
DB102 Real Image
Same model may have multiple batches, images only for reference.

DB102

Part No DB102
Manufacturer SMC Diode Solutions
Catalog Bridge Rectifiers
Description BRIDGE RECT 1PHASE 100V 1A DB-M / Bridge Rectifier Single Phase Standard 100 V Through Hole DB-M
Datasheet
DB102 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Bridge Rectifiers
Mfr SMC Diode Solutions
Package Tube
Product Status Active
Diode Type Single Phase
Technology Standard
Voltage - Peak Reverse (Max) 100 V
Current - Average Rectified (Io) 1 A
Voltage - Forward (Vf) (Max) @ If 1.1 V @ 1 A
Current - Reverse Leakage @ Vr 5 µA @ 100 V
Temperature Range - Operating -55°C ~ 150°C (TJ)
Mounting Type Through Hole
Package / Case 4-EDIP (0.321", 8.15mm)
Supplier Device Package DB-M
Base Product Number DB102
Standard Package 50 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Affected
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 584096-DB102
Ultra Librarian 3D Model Ultra Librarian DB102 CAD Model

Description

The 584096-DB102 is a single-phase bridge rectifier diode designed for use in electronic circuits.

  • Maximum Peak Reverse Voltage: 100V.
  • Average Rectified Current: 1A.
  • Forward Voltage Drop @ 1A: 1.1V.
  • Reverse Leakage Current @ Maximum Reverse Voltage: 5 microamps.
  • Mounting: Through-Hole.
  • Package Type: 4-EDIP (0.321", 8.15mm).
  • Operating Temperature: -55°C to 150°C.
  • Manufacturer: SMC Diode Solutions.
  • Commonly Used In: power supplies, battery chargers, and other electronic devices.
