ES1J Real Image ES1J real image3943
ES1J Real Image ES1J real image3943
Same model may have multiple batches, images only for reference.

ES1J

Part No ES1J
Manufacturer SMC Diode Solutions
Catalog Diodes, Rectifiers - Single
Description DIODE GEN PURP 600V 1A SMA / Diode 600 V 1A Surface Mount SMA (DO-214AC)
Datasheet
ES1J Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Single Diodes
Mfr SMC Diode Solutions
Package Tape & Reel
Product Status Active
Technology Standard
Voltage - DC Reverse (Vr) (Max) 600 V
Current - Average Rectified (Io) 1A
Voltage - Forward (Vf) (Max) @ If 1.7 V @ 1 A
Speed Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr) 35 ns
Current - Reverse Leakage @ Vr 5 µA @ 600 V
Capacitance @ Vr, F 45pF @ 4V, 1MHz
Mounting Type Surface Mount
Package / Case DO-214AC, SMA
Supplier Device Package SMA (DO-214AC)
Operating Temperature - Junction -55°C ~ 150°C
Base Product Number ES1
Standard Package 5,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Affected
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 124171-ES1J
Package Tape & Reel (TR);Cut Tape (CT)
Voltage - DC Reverse (Vr) (Max) 600V
Voltage - Forward (Vf) (Max) @ If 1.7V @ 1A
Reverse Recovery Time (trr) 35ns
Current - Reverse Leakage @ Vr 5µA @ 600V
Grade -
Supplier Device Package DO-214AC (SMA)
Ultra Librarian 3D Model Ultra Librarian ES1J CAD Model

Description

ES1J - Ultra Fast Recovery Rectifier

The ES1J Rectifier offers ultra-fast recovery time and is built to handle high voltage and current applications. It provides reliable rectification in circuits demanding quick recovery and low forward voltage drop.

  • Applications:
    • LED Lighting Systems
    • Telecommunications Equipment
    • High-Frequency Rectification
    • Power Converters
    • Automated Test Equipment
  • Features and Benefits:
    • Peak Repetitive Reverse Voltage: 600V
    • Forward Current: 1 Ampere
    • Rapid reverse recovery reduces switching losses
    • Compact DO-214AC (SMA) for efficient space utilization
    • High efficiency due to low leakage current
  • Additional Details:
    • Operating Temperature Range: -65°C to +150°C
    • Meets international safety and performance standards
    • Complies with green environmental regulations
