Same model may have multiple batches, images only for reference.
GBU1506TB Real Image
Same model may have multiple batches, images only for reference.

GBU1506TB

Part No GBU1506TB
Manufacturer SMC Diode Solutions
Catalog Bridge Rectifiers
Description BRIDGE RECT 1PHASE 600V 15A GBU
Datasheet
GBU1506TB Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer SMC Diode Solutions
Diode Type Single Phase
Technology Standard
Voltage - Peak Reverse (Maximum) 600V
Current - Average Rectified (Io) 15A
Voltage - Forward (Vf) (Maximum) @ If 1.1V @ 15A
Current - Reverse Leakage @ Vr 5μA @ 600V
Operating Temperature Range -55°C ~ 150°C (TJ)
Mounting Style Through Hole
Package 4-ESIP
Manufacturer Package GBU
Win Source Part Number 775016-GBU1506TB
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian GBU1506TB CAD Model

Description

The GBU1506TB is a single-phase standard diode with a current average rectified (Io) of 15A.

  • Current reverse leakage @ Vr: 5μA @ 600V
  • Mounting: through-hole
  • Package: 4-ESIP
  • Voltage peak reverse (maximum): 600V
  • Voltage forward (Vf) (maximum) @ If: 1.1V @ 15A
  • Manufacturer package: GBU
