MURF1560 Sangdest Microelectronic (Nanjing) Co., Ltd
Same model may have multiple batches, images only for reference.

MURF1560

Part No MURF1560
Manufacturer SMC Diode Solutions
Catalog Diodes, Rectifiers - Single
Description DIODE GEN PURP 600V 15A ITO220AC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Single Diodes
Mfr SMC Diode Solutions
Package Tube
Product Status Obsolete
Technology Standard
Voltage - DC Reverse (Vr) (Max) 600 V
Current - Average Rectified (Io) 15A
Voltage - Forward (Vf) (Max) @ If 1.7 V @ 15 A
Speed Fast Recovery =< 500ns, > 200mA (Io)
Reverse Recovery Time (trr) 50 ns
Current - Reverse Leakage @ Vr 25 µA @ 600 V
Mounting Type Through Hole
Package / Case TO-220-2 Full Pack, Isolated Tab
Supplier Device Package ITO-220AC
Operating Temperature - Junction -65°C ~ 150°C
Standard Package 50 pcs
Moisture Sensitivity Level (MSL) 1 (Unlimited)
REACH Status REACH Affected
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 645954-MURF1560
Ultra Librarian 3D Model Ultra Librarian MURF1560 CAD Model

Description

The MURF1560 is a fast recovery rectifier diode designed for high voltage applications. It has a voltage rating of 600V and an average rectified current of 15A. The MURF1560 is a fast recovery rectifier diode designed for high voltage applications. It has a voltage rating of 600V and an average rectified current of 15A.

  • Voltage Rating: 600V
  • Average Rectified Current: 15A
  • Forward Voltage Drop: 1.7V @ 15A
  • Reverse Recovery Time: 50ns
  • Reverse Leakage Current: 25μA @ 600V
  • Operating Temperature Range: -65°C to 150°C
  • Mounting: Through-hole
  • Package: Tube with 50 pieces
