D44C4 Boca Semiconductor Corporation
Same model may have multiple batches, images only for reference.

D44C4

Part No D44C4
Manufacturer Solid State Inc.
Catalog Transistors (BJT) - Single
Description TRANS NPN 45V 4A TO220
Datasheet
D44C4 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Transistors - Bipolar (BJT) - Single Bipolar Transistors
Mfr Solid State Inc.
Package Bulk
Product Status Active
Transistor Type NPN
Current - Collector (Ic) (Max) 4 A
Voltage - Collector Emitter Breakdown (Max) 45 V
Vce Saturation (Max) @ Ib, Ic 500mV @ 100mA, 1A
Current - Collector Cutoff (Max) 10µA
DC Current Gain (hFE) (Min) @ Ic, Vce 25 @ 1A, 1V
Power - Max 30 W
Frequency - Transition 50MHz
Temperature Range - Operating -55°C ~ 150°C (TJ)
Mounting Type Through Hole
Package / Case TO-220-3
Supplier Device Package TO-220
Standard Package 10 pcs
MSL Level 1 (Unlimited)
REACH Status Vendor Undefined
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 583492-D44C4
Ultra Librarian 3D Model Ultra Librarian D44C4 CAD Model

Description

The D44C4 is an NPN bipolar transistor designed for general-purpose switching applications.

  • Power Rating: 30W (maximum)
  • Collector Current: 4A (maximum)
  • Collector-Emitter Voltage Breakdown: 45V
  • Package: TO-220-3
  • Mounting: Through-hole
  • Vce Saturation: 500mV @ 1A
  • DC Current Gain (hFE): 25 @ 1A and 1V
  • Application: Audio amplifiers, voltage regulators, switching circuits
  • Status: Active
  • Packaging: Bulk
  • Standard Package: 10 pcs
