The HDMI05-CL01F3 from STMicroelectronics is a state-of-the-art transient voltage suppressor (TVS) specifically designed to protect HDMI interfaces. This device is particularly suitable for applications where high video and audio fidelity is essential, such as in high-definition televisions, computer monitors, digital signage, and multimedia projectors.

Key Features

• High ESD Protection: The HDMI05-CL01F3 offers robust electrostatic discharge (ESD) protection for HDMI signals, safeguarding against static electricity and other transient voltage events.
• Low Capacitance: With its low line capacitance, the device ensures minimal signal degradation, maintaining the integrity of high-speed HDMI signals.
• High Integration: This TVS integrates protection for all lines in an HDMI interface, providing comprehensive defense against voltage transients.
• Flow-Through Design: The layout of the HDMI05-CL01F3 follows a flow-through design, which simplifies PCB layout and reduces signal distortion for improved signal integrity.

Applications

The HDMI05-CL01F3 is suitable for a wide range of applications that require HDMI connectivity. Its high level of protection and performance makes it an ideal choice for:

• High-definition televisions (HDTVs)
• Computer monitors and laptops
• Digital signage solutions
• Multimedia projectors
• Set-top boxes and media players
• Game consoles

Technical Specifications

The HDMI05-CL01F3 boasts impressive technical specifications that ensure reliable protection and performance:

• Stand-off voltage: 5 V
• Maximum clamping voltage: 8.5 V
• ESD protection up to 15 kV (air discharge)
• Low line capacitance for high-speed data lines
• Compliant with HDMI 2.0 and previous standards

In summary, the HDMI05-CL01F3 from STMicroelectronics provides robust ESD protection for HDMI interfaces, ensuring that your high-definition audio and video equipment performs at its best while being shielded from harmful voltage spikes. With its low capacitance, high integration, and flow-through design, it stands out as a superior choice for safeguarding sensitive HDMI-enabled devices.
