L293DD013TR

Part No L293DD013TR
Manufacturer STMicroelectronics
Catalog PMIC - Motor Drivers, Controllers
Description IC MOTOR DRIVER PAR 20-SOIC
Datasheet
Sample
Rohs State Need to verify
ECAD Module ECAD

Shipping Information

Shipped from HK warehouse
Expected Shipping Date
Ship today if order in (HKT)
Supplier Lead-Time Call for availability
Estimate shipping fee
Enter your destination to get a shipping estimate
Estimate Shipping Fee
Pricing & Ordering $2.4211 Historical reference price : is the price that a customer announces that it is willing to pay for this component in the previous period, only for reference.
Quantity
Unit Price
Ext. Price
16+
$3.2510
$52.016
38+
$2.6670
$101.346
59+
$2.5840
$152.456
80+
$2.5000
$200.000
104+
$2.4170
$251.368
139+
$2.1670
$301.213
* The above prices does not include taxes and freight rates, which will be calculated on the order pages.
Availability: 36,700 pieces
MOQ: 16 pcs
Order Increment : 1 pcs
*Need More Quantity? *Request a Bulk Quantity Quotation?
Estimate shipping
Enter your destination to get a shipping estimate

*

Products specifications

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Motor Type - Stepper Bipolar
Motor Type - AC, DC Brushed DC
Purpose Driver - Fully Integrated, Control and Power Stage
Applications General Purpose
Output Current 600mA
Supply Voltage - Operating 4.5 V to 36 V
Voltage - Load 4.5 V to 36 V
Temperature Range - Operating -40°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 20-SOIC
Win Source Part Number 018236-L293DD013TR
Family Name L293D
Introduction Date June 24, 1996
ECCN EAR99
Country of Origin United States of America
Halogen Free Not Compliant
Estimated EOL Date 2025
Is this a common-used part? Yes
Popularity High
Fake Threat In the Open Market 43 pct.
Supply and Demand Status Sufficient
Alternative Parts
(Cross-Reference)
IR3220S;  TLE4205GNTMA1; L293D-W;

Description

The L293DD013TR from STMicroelectronics is a robust and versatile motor driver integrated circuit designed to efficiently drive inductive loads such as relays, solenoids, DC and bipolar stepping motors. As part of the L293D series, it is particularly notable for its high-current output capability and the inclusion of diodes for back EMF protection.

Key Features

  • Output Current: The device can deliver up to 600 mA continuous current per channel to your motor or other inductive loads, with peak currents up to 1.2 A, making it suitable for a wide range of applications.
  • Supply Voltage Range: It operates with a supply voltage ranging from 4.5 V to 36 V, which provides flexibility in accommodating different power levels required by various devices.
  • Built-in Clamp Diodes: The inclusion of clamp diodes is a significant advantage as they provide indispensable protection against inductive voltage spikes that occur when turning off inductive loads.
  • Channel Configuration: The L293DD013TR can drive up to four channels, making it an excellent choice for controlling two DC motors or one stepping motor in both directions.
  • Separate Input-Logic Supply: The device features an independent logic supply input which allows the internal logic to operate at a lower voltage, typically 5 V, while still driving motors at a higher voltage.

Applications

The L293DD013TR is suitable for a variety of applications in the consumer, industrial, and automotive sectors. Its ability to drive both DC and stepping motors makes it an ideal choice for use in:

  • Printers and office automation machines
  • Small robotics projects
  • Control systems for valves and actuators
  • Positioning and servo control in embedded systems

Package and Quality

The motor driver comes in a PowerSO20 package, which is not only space-efficient but also provides excellent power dissipation characteristics. The device is available in tape and reel packaging, with the suffix 'TR' indicating its readiness for automated assembly processes. STMicroelectronics ensures high manufacturing standards, with the L293DD013TR being compliant with RoHS and designed to meet the rigorous demands of the industrial and automotive industries.
