Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Output Type Transistor Driver
Purpose Step-Up/Step-Down
Topology Flyback
Number of Outputs 1
Output Phases 1
Supply Voltage - Operating 7.6 V to 20 V
Frequency - Switching Up to 1MHz
Duty Cycle (Max) 93%
Synchronous Rectifier Yes
Clock Sync No
Control Features Current Limit, Frequency Control, Soft Start
Temperature Range - Operating -40°C to 150°C (TJ)
Case / Package 16-SOIC
Win Source Part Number 070588-L5991AD
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian L5991AD CAD Model

Description

STMicroelectronics Product L5991AD Overview

The L5991AD from STMicroelectronics is a high-performance power management integrated circuit designed to cater to a wide array of applications. This robust component is tailored to deliver efficient and reliable power control, making it an ideal choice for designers looking to optimize their power supply systems.

Key Features

  • Versatile Voltage Range: The L5991AD operates over a broad voltage range, providing flexibility for use in various system configurations.
  • High-Efficiency Design: With its advanced design, the L5991AD ensures high efficiency in power conversion, which is crucial for minimizing energy loss and heat generation.
  • Protection Features: It includes multiple protection features such as overvoltage, overcurrent, and thermal shutdown, ensuring the safety and longevity of both the IC and the system it is part of.
  • Adjustable Output: The output voltage of the L5991AD is adjustable, providing designers with the flexibility to tailor the power supply to specific needs.

Applications

The L5991AD is designed for a diverse range of applications, including but not limited to:

  • Telecommunications equipment
  • Consumer electronics
  • Computer systems
  • Industrial controls
  • Networking hardware

Technical Specifications

The technical specifications of the L5991AD make it a highly capable component in power management systems:

  • Adjustable switching frequency
  • Soft-start capability
  • Under-voltage lockout
  • Low standby current

Quality and Reliability

STMicroelectronics is renowned for its commitment to quality and reliability, and the L5991AD is no exception. Manufactured under stringent conditions, this IC meets high standards, ensuring consistent performance and durability across a range of environmental conditions.

Support and Resources

Designers and engineers can access a wealth of support and resources for the L5991AD, including datasheets, application notes, and technical support from STMicroelectronics, facilitating a smooth integration into various power management solutions.
