Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Tube/Rail
Status Active
Purpose Step-Down
Topology Buck
Output Type Adjustable
Number of Outputs 1
Minimum Input Voltage 4.5V
Maximum Input Voltage 38V
Nominal Output Voltage (Min/Fixed) 0.6V
Maximum Output Voltage 38V
Output Current 3A
Frequency - Switching 250kHz to 1MHz
Synchronous Rectifier No
Temperature Range - Operating -40°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 8-HSOP Exposed Pad
Win Source Part Number 1051395-L7986TA
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian L7986TA CAD Model

Description

The L7986TA from STMicroelectronics is a highly efficient, monolithic synchronous step-down switching regulator that is designed to deliver up to 3 A of continuous output current. Operating from a wide input voltage range of 4.5 V to 38 V, this regulator is suitable for a variety of applications, including industrial, automotive, and consumer electronics.

Key Features

  • High Efficiency: With a synchronous rectification topology, the L7986TA achieves high efficiency, which is critical for reducing heat dissipation and improving system reliability.
  • Adjustable Output Voltage: The output voltage can be set from 0.8 V to VIN, with an external resistor divider, providing design flexibility for a wide range of applications.
  • Wide Input Voltage Range: The regulator operates over a 4.5 V to 38 V input voltage range, making it suitable for use in systems with varying supply voltages.
  • High Switching Frequency: A switching frequency up to 1 MHz allows the use of small surface-mount inductors and capacitors, saving board space and reducing BOM cost.
  • Protection Features: The device includes overcurrent protection, thermal shutdown, and under-voltage lockout (UVLO) to ensure safe operation under abnormal operating conditions.
  • Adjustable Soft-Start: An adjustable soft-start prevents inrush current at startup, contributing to system stability.

Applications

The versatility of the L7986TA makes it ideal for a wide range of applications, including:

  • Power supplies for FPGAs, DSPs, and microcontrollers
  • Automotive applications compliant with ISO 7637-2
  • Industrial power systems
  • Consumer electronics
  • Point of load conversions

With its robust feature set and flexible design options, the L7986TA from STMicroelectronics is a powerful solution for designers looking to optimize power efficiency and performance in their next project.
