Products specifications Report Issue?

Categories Circuit Protection
Manufacturer STMicroelectronics
Packaging Cut Tape (CT)
Status Obsolete
Type Zener
Unidirectional Channels 1
Voltage - Reverse Standoff 20V
Voltage - Breakdown (Minimum) 22V
Voltage - Clamping (Maximum) at Ipp 32V
Current - Peak Pulse (10/1000μs) 331A (8/20μs)
Power - Peak Pulse 2000W (2kW)
Power Line Protection No
Applications General Purpose
Temperature Range - Operating -55°C ~ 150°C
Mounting Style Through Hole
Manufacturer Package DO-201AA, DO-27, Axial
Supplier Device Package DO-201
Family Part Number LNBTVS
Manufacturer Pack Quantity 1
MSL Level 1 (Unlimited)
Win Source Part Number 1202627-LNBTVS4-221
Manufacturer Homepage www.st.com
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian LNBTVS4-221 CAD Model

Description

STMicroelectronics LNBTVS4-221: Robust Surge Protection Device

The LNBTVS4-221 from STMicroelectronics is a dedicated transient voltage suppression (TVS) diode designed to protect sensitive electronic circuits from voltage spikes and surges. This device is an integral component for safeguarding systems against the detrimental effects of overvoltage events, such as those caused by lightning strikes, electrostatic discharge (ESD), or switching transients in industrial and consumer applications.

Key Features

  • Low Clamping Voltage: The LNBTVS4-221 provides a low clamping voltage, ensuring that any transient voltage spikes are clamped to a safe level, protecting downstream circuits from overvoltage damage.
  • High Surge Capability: This device is capable of withstanding high surge currents, making it suitable for applications that are exposed to severe transient overvoltage conditions.
  • Fast Response Time: With a rapid response to transient events, the LNBTVS4-221 minimizes the exposure time of sensitive components to potentially harmful voltages.
  • Low Leakage Current: The diode offers a low leakage current in standby mode, contributing to the overall energy efficiency of the system it protects.
  • Bidirectional Protection: It provides bidirectional clamping which is crucial for AC signal lines or where the polarity of the transient could be either positive or negative.

Applications

The LNBTVS4-221 is versatile and can be used in a wide range of applications. It is particularly well-suited for:

  • Telecommunication systems
  • Power supply units
  • Automotive electronics
  • Industrial control systems
  • Consumer electronics such as TVs and PCs

Reliability and Quality

STMicroelectronics is renowned for its commitment to quality and reliability, and the LNBTVS4-221 is no exception. It is manufactured to meet high industry standards, ensuring long-term reliability and performance in even the most demanding situations. With its robust surge protection capabilities, this TVS diode is an essential component for any design where electronic circuit protection is a priority.

For detailed specifications and application notes, designers and engineers are encouraged to consult the datasheet and support documentation available from STMicroelectronics.
