Products specifications

Category Integrated Circuits (ICs)>PMIC - Battery Chargers
Mfr STMicroelectronics
Package Tape & Reel
Battery Chemistry Lithium Ion/Polymer
Number of Cells 1
Current - Charging Constant - Programmable
Programmable Features Timer
Fault Protection Over Current, Over Temperature, Over Voltage, Reverse Current, Short Circuit
Charge Current - Max 450mA
Battery Pack Voltage 4.2V
Voltage - Supply (Max) 5.4V
Temperature Range - Operating -40°C ~ 85°C (TA)
Mounting SMD (SMT)
Package / Case 30-UFBGA, FCBGA
Supplier Device Package 30-FlipChip (2.59x2.25)
Base Product Number STBC02
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Other Names 497-16562-6-ND,497-STBC02BJRTR,-1138-STBC02BJRCT,497-16562-2,497-STBC02BJRCT,497-16562-2-ND,497-16562-1,-1138-STBC02BJRTR,497-16562-6,497-16562-1-ND,-1138-STBC02BJRDKR,497-STBC02BJRDKR
Standard Package 3,000
Win Source Part Number 960786-STBC02BJR
Ultra Librarian 3D Model Ultra Librarian STBC02BJR CAD Model

Description

STBC02BJR - Power Management IC from STMicroelectronics

The STBC02BJR is a highly integrated power management integrated circuit (PMIC) designed by STMicroelectronics, tailored for efficient battery charging and power management in a wide array of portable applications. This versatile chip is specifically engineered to cater to the needs of lithium-ion and lithium-polymer battery-powered systems, ensuring safe and efficient charging along with a host of other power management features.

At the heart of the STBC02BJR lies its linear battery charger which offers a programmable charging current up to 950mA, allowing for flexibility in charging different battery capacities. The device ensures safe operation with its dedicated charge termination and auto-recharge feature, alongside thermal protection and a temperature monitoring interface that safeguards the battery during the charging process.

The PMIC integrates a DC-DC step-down converter, delivering a stable output voltage to power the system or additional peripherals. This high-efficiency converter helps prolong battery life by minimizing power loss during operation. Additionally, the STBC02BJR incorporates a short-circuit protection mechanism and a low battery reset function, which contribute to the overall reliability and stability of the power management system.

One of the key advantages of the STBC02BJR is its support for various power-saving modes, including a shipping mode that significantly reduces power consumption when the device is not in use. This feature is particularly useful for extending the shelf life of battery-powered products during storage or transportation.

The STBC02BJR comes in a compact VFQFPN-20 package, making it an ideal choice for space-constrained applications. Its small footprint, combined with a minimal external component count, allows for a cost-effective and straightforward implementation in portable devices such as smart wearables, wireless headphones, and IoT sensors.

In summary, the STBC02BJR by STMicroelectronics offers a comprehensive solution for power management, bringing together battery charging, power conversion, and protection features into a single, efficient, and compact package. Its versatility and high performance make it an excellent choice for designers looking to optimize their portable and rechargeable applications.
