Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Polarity N-Channel
Technology MOSFET
Drain-Source Breakdown Voltage 60V
Continuous Drain Current at 25°C 24A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 4.5V, 10V
Gate-Source Threshold Voltage 2.5V @ 250μA
Max Gate Charge 26nC @ 10V
Max Input Capacitance 1320pF @ 25V
Maximum Gate-Source Voltage ±20V
Power Dissipation (Max) 40W (Tc)
Maximum Rds On at Id,Vgs 25 mOhm @ 12A, 10V
Temperature Range - Operating -55°C to 175°C (TJ)
Mounting SMD (SMT)
Case / Package DPAK
Dimension TO-252-3, DPak (2 Leads + Tab), SC-63
Win Source Part Number 1102876-STD30N6LF6AG
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian STD30N6LF6AG CAD Model

Description

The STD30N6LF6AG is a high-performance, N-channel Power MOSFET designed and manufactured by STMicroelectronics. This state-of-the-art MOSFET is part of STMicroelectronics' STripFET™ VI DeepGATE™ technology, which provides superior power efficiency and thermal performance. It is specifically engineered to address a wide array of power applications, making it an ideal choice for power supply, DC-DC converters, motor control, and other high-efficiency power management functions.

Key Features

  • Low On-Resistance: The STD30N6LF6AG boasts an exceptionally low on-resistance (R<sub>DS(on)) of just 59 mΩ max, which significantly reduces conduction losses and enhances overall efficiency.
  • High Current Capability: With a continuous drain current (I<sub>D) of 30 A, this MOSFET can handle high current loads, making it suitable for demanding applications.
  • High Voltage Threshold: The device can support a drain-source voltage (V<sub>DS) up to 60 V, providing a good safety margin for a variety of circuits.
  • Low Gate Charge: A low gate charge (Q<sub>g) facilitates faster switching, contributing to the device's high-speed performance and reduced switching losses.
  • 100% Avalanche Tested: Ensuring reliability and robustness, each device is subjected to an avalanche test, verifying its capability to withstand challenging conditions.

Applications

The versatility of the STD30N6LF6AG MOSFET allows it to be used in a broad range of applications, including:

  • Switch Mode Power Supplies (SMPS)
  • DC-DC Converters
  • Power Management Systems
  • Motor Drives and Control Circuits
  • Automotive Applications
  • LED Lighting Solutions

Package and Quality

The STD30N6LF6AG comes in a TO-220 package, which is widely used and recognized for its ease of mounting and excellent thermal performance. STMicroelectronics is committed to delivering high-quality products, and as such, this MOSFET is produced in ISO 9001 and ISO/TS 16949 certified facilities, ensuring that it meets the stringent requirements of the automotive industry and other high-reliability environments.
