The STD75N3LLH6 is a high-performance N-channel Power MOSFET from the industry-leading manufacturer STMicroelectronics. This MOSFET utilizes STMicroelectronics' exclusive STripFET™ VI DeepGATE technology to achieve excellent RDS(on) performance, ensuring high efficiency in power conversion applications.

Key Features

• Low On-Resistance: The device boasts an exceptionally low drain-source on-resistance (RDS(on)) of just 7.5 mΩ, which greatly reduces conduction losses and improves overall efficiency.
• High Current Capability: With a continuous drain current (ID) of 80A, the STD75N3LLH6 can handle high current loads, making it suitable for demanding applications.
• High Voltage Threshold: The MOSFET operates at a standard threshold voltage, facilitating ease of use in a wide array of circuit designs.
• 100% Avalanche Tested: Each unit is rigorously tested for avalanche ruggedness, ensuring reliability and durability even under stress.

Applications

The versatility of the STD75N3LLH6 allows it to be used in a broad spectrum of electronic circuits. It is particularly well-suited for:

• Switch Mode Power Supplies (SMPS)
• High-efficiency DC-DC converters
• Motor control applications
• Power management functions

Package and Environmental Compliance

The STD75N3LLH6 is available in a DPAK package, which is designed to optimize the thermal performance and footprint. The device is compliant with RoHS (Restriction of Hazardous Substances) and is designed to meet the environmental standards of today's green energy requirements.

Conclusion

With its robust design, thermal efficiency, and high current handling capability, the STD75N3LLH6 from STMicroelectronics is an ideal choice for power engineers looking to improve the performance and reliability of their power systems. Its compliance with environmental standards also makes it a sustainable choice for modern electronic designs.
