Products specifications

Category Development Boards, Kits, Programmers>Evaluation and Demonstration Boards and Kits
Mfr STMicroelectronics
Series STM32
Package Bulk
Product Status Obsolete
Type Power Management
Function Motor Controller/Driver
Embedded Yes, MCU, 32-Bit
Utilized IC / Part STM32F100CB
Supplied Contents Board(s)
Secondary Attributes Serial Interface
Other Names 497-13149
Standard Package 1
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8473.30.1180
Win Source Part Number 1284454-STEVAL-IHM033V1
Ultra Librarian 3D Model Ultra Librarian STEVAL-IHM033V1 CAD Model

Description

STEVAL-IHM033V1 - STMicroelectronics Low Voltage Three-Phase Inverter Power Board

The STEVAL-IHM033V1 is a sophisticated, low voltage, three-phase inverter power board designed by STMicroelectronics. This power board is specifically engineered for applications requiring efficient and precise control over three-phase motors, making it an ideal choice for a wide range of industrial, consumer, and automotive applications.

At the heart of the STEVAL-IHM033V1 is STMicroelectronics' advanced STM32 microcontroller, which provides the computational power and flexibility to handle complex motor control algorithms. This microcontroller works in tandem with a trio of STGIPN3H60 intelligent power modules, which are capable of driving the three-phase motor with a maximum voltage of up to 250 V and a current of up to 2 A.

The board is designed with a user-friendly interface that includes a range of features for easy integration and testing. It offers several control methods, including six-step, field-oriented control (FOC), and sensorless vector control, which can be selected to match the specific requirements of the motor and application. Additionally, the board is equipped with overcurrent, overvoltage, and undervoltage lockout protection, ensuring safe and reliable operation under various conditions.

For developers looking to customize and optimize motor control, the STEVAL-IHM033V1 is supported by the ST Motor Control Workbench software, which provides a comprehensive development environment. This software allows for fine-tuning of motor control parameters, real-time monitoring, and debugging, significantly reducing development time and effort.

The compact design of the STEVAL-IHM033V1, along with its robust set of features, makes it an excellent platform for rapid prototyping and development of motor control solutions. Whether for educational purposes, R&D, or commercial product development, the STEVAL-IHM033V1 offers a versatile and powerful tool to drive innovation in motor control applications.

For detailed technical specifications, application notes, and support documentation, users can visit the STMicroelectronics website.
