Products specifications Report Issue?

Category Development Boards, Kits, Programmers>Evaluation Boards - DC/DC & AC/DC (Off-Line) SMPS
Mfr STMicroelectronics
Package Bulk
Main Purpose DC/DC, Step Down
Outputs and Type 1, Non-Isolated
Voltage - Output 5V
Current - Output 2A
Voltage - Input 4.5V ~ 60V
Regulator Topology Buck
Frequency - Switching 500kHz
Board Type Fully Populated
Supplied Contents Board(s)
Utilized IC / Part L7987L
Base Product Number STEVAL
Other Names 497-17062
Standard Package 1
RoHS Status Not applicable
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.40.9580
Win Source Part Number 1284242-STEVAL-ISA198V1
Ultra Librarian 3D Model Ultra Librarian STEVAL-ISA198V1 CAD Model

Description

STEVAL-ISA198V1 - An Advanced Energy-Saving PWM SMPS Controller

The STEVAL-ISA198V1 from STMicroelectronics is a state-of-the-art product designed for high-efficiency power supply applications. This evaluation board showcases the capabilities of the VIPer26K high-voltage converter, which integrates a PWM controller and a 1050 V avalanche-rugged power MOSFET.

Key Features

  • High Voltage Capability: The VIPer26K allows for direct 265 VAC input with a staggering 1050 V MOSFET integrated, making it suitable for a wide range of input voltages and offering excellent power supply reliability.
  • Energy Efficiency: With its advanced PWM controller, the STEVAL-ISA198V1 ensures energy-saving operation, particularly suitable for LED lighting applications, adapters, and power supplies that require high energy efficiency.
  • Compact Design: The evaluation board is designed with a compact form factor, which makes it an excellent choice for applications where space is at a premium.
  • Flexibility: The board can be used to evaluate different power supply configurations, such as buck, buck-boost, or flyback converters, providing designers with a versatile platform for testing and development.
  • Thermal Protection: The VIPer26K comes with built-in thermal shutdown, overcurrent protection, and a hysteresis thermal protection feature, ensuring safe operation under a variety of conditions.

Applications

The STEVAL-ISA198V1 is ideal for a broad range of applications, including but not limited to:

  • SMPS (Switched-Mode Power Supply) for LED lighting
  • Adapters for consumer electronics
  • Auxiliary power supplies for home appliances
  • Industrial power supplies

With its robust design and advanced features, the STEVAL-ISA198V1 provides an excellent platform for developing and testing power supply solutions that require high voltage, reliability, and efficiency. Whether you're working on a new design or looking to improve an existing one, the STEVAL-ISA198V1 is an invaluable tool for any power supply engineer or designer.
