The STL110N10F7 is a high-performance, N-channel Power MOSFET designed and manufactured by STMicroelectronics, a global semiconductor leader. This powerful component is part of ST's STripFET F7 series, which is renowned for its low on-state resistance and high switching performance.

Key Features

• Low On-Resistance: The STL110N10F7 boasts an exceptionally low on-resistance (R<sub>DS(on)) of only 9.3 mΩ max, which significantly reduces conduction losses and enhances overall efficiency.
• High Current Capability: With a continuous drain current (I<sub>D) of 110 A, this MOSFET can handle high current applications with ease, making it an excellent choice for power-intensive circuits.
• High Switching Performance: The device is optimized for fast switching, reducing switching losses and improving performance in applications such as DC/DC converters, motor drivers, and power management systems.
• 100% Avalanche Tested: Each unit is rigorously tested for avalanche ruggedness, ensuring reliability and robustness in harsh environments.
• Low Gate Charge: A low gate charge (Q<sub>g) facilitates faster switching and reduces driver power requirements.
• Environmentally Friendly: The STL110N10F7 is compliant with RoHS and Halogen-free, reflecting STMicroelectronics' commitment to environmental sustainability.

Applications

The STL110N10F7 is suitable for a wide range of high-efficiency applications, including:

• Switch Mode Power Supplies (SMPS)
• High Current DC/DC Converters
• Motor Control Circuits
• Power Management Systems
• Synchronous Rectification

Package and Quality

The device comes in a robust and compact PowerFLAT 5x6 package, which not only saves space but also enhances thermal performance. STMicroelectronics ensures that the STL110N10F7 meets the highest quality and performance standards, providing engineers with a reliable and high-performing solution for their power management challenges.
