Products specifications

Manufacturer STMicroelectronics
Packaging Reel
FET Type P-Channel
Technology MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss) 60V
Current - Continuous Drain (Id) at 25°C 4A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Rds On (Maximum) at Id, Vgs 160mOhm at 1.5A, 10V
Vgs(th) (Maximum) at Id 4V at 250μA
Gate Charge (Qg) (Maximum) at Vgs 6.4nC at 10V
Maximum Vgs ±20V
Input Capacitance (Ciss) (Maximum) at Vds 340pF at 48V
Power Dissipation (Maximum) 75W (Tc)
Temperature Range - Operating -55°C ~ 175°C
Mounting Style SMD
Supplier Device Package PowerFlat (5x6)
Manufacturer Package 8-PowerVDFN
Part Number Series STL12
Manufacturer Pack Quantity 3,000
MSL Level 1 (Unlimited)
Popularity Low
Supply and Demand Status Limited
Win Source Part Number 813431-STL12P6F6
Ultra Librarian 3D Model Ultra Librarian STL12P6F6 CAD Model

Description

STL12P6F6 Power MOSFET by STMicroelectronics

The STL12P6F6 is a high-performance Power MOSFET presented by STMicroelectronics, a leader in the semiconductor industry. This MOSFET is part of the STripFET™ VI DeepGATE™ technology line, designed to deliver both low on-resistance and low gate charge, resulting in highly efficient power conversion in various applications.

With a drain-source voltage (V<sub>DS) of -60V and a continuous drain current (I<sub>D) of -12A, the STL12P6F6 is well-suited for handling significant power levels. The device also features a low threshold voltage, which enhances its performance at low operating voltages, making it versatile for use in low voltage applications.

The STL12P6F6 offers an extremely low on-state resistance (R<sub>DS(on)) of just 0.0195 Ω max, which minimizes conduction losses and improves overall efficiency. This characteristic, combined with its low gate charge (Q<sub>g), allows for rapid switching, further enhancing the efficiency of the device in applications such as DC-DC converters, motor control circuits, and power management systems.

The device is encapsulated in a PowerFLAT™ 5x6 package, which is not only compact but also offers excellent thermal performance. This packaging technology contributes to the MOSFET's high power density and reliability, making it an ideal choice for space-constrained applications that require efficient heat dissipation.

Safety and reliability are paramount in power devices, and the STL12P6F6 incorporates features such as 100% avalanche tested and a very low intrinsic capacitance. These features ensure that the device can handle the toughest conditions and provide a long operational lifespan.

In summary, the STL12P6F6 from STMicroelectronics is a robust and efficient Power MOSFET that offers designers a high-performance solution for a wide range of power applications. Its low R<sub>DS(on), low gate charge, and compact, thermally adept packaging make it a go-to component for engineers looking to optimize power efficiency and reliability.
