STM32F105RBT6TR Microcontroller

The STM32F105RBT6TR is a cutting-edge microcontroller product from STMicroelectronics, renowned for its high performance and integration. This device is part of the STM32F1 series, which is based on the ARM Cortex-M3 core, offering a blend of high-speed processing capabilities with the low power consumption that is a hallmark of ARM technology.

Key Features

• Core: ARM Cortex-M3 32-bit RISC core operating at a 72 MHz frequency.
• Memory: Comes equipped with 128 Kbytes of Flash memory and 20 Kbytes of SRAM, providing ample space for complex applications.
• I/O Ports: Features up to 51 I/O ports with interrupt capability, which allows for versatile peripheral connections and system functionalities.
• Connectivity: Includes a USB 2.0 full-speed device/host/OTG controller with on-chip PHY, which ensures robust connectivity options.
• ADCs: Contains two 12-bit analog-to-digital converters, enhancing its ability to interface with analog sensors and devices.
• Timers: Boasts three general-purpose 16-bit timers plus one PWM timer, which help in managing time-critical operations.
• Debugging: Supports serial wire debug (SWD) and JTAG interfaces, facilitating easier development and troubleshooting.
• Package: Available in a 64-pin LQFP package, which is suitable for space-constrained applications.

Applications

The STM32F105RBT6TR is designed for a wide range of applications, particularly those that require high-speed communication interfaces, such as:

• Industrial control systems
• Medical devices
• Home automation and smart home devices
• Automotive applications
• Complex user interfaces

Environmental and Quality Certifications

STMicroelectronics is committed to environmental sustainability and quality. The STM32F105RBT6TR is manufactured with the consideration for eco-friendly practices and adheres to multiple industry-standard certifications, ensuring reliability and performance for the end-user.
