Product Overview: STM32F413RHT6

The STM32F413RHT6 is a high-performance microcontroller unit (MCU) from STMicroelectronics, designed to offer a balanced combination of computing power, reduced power consumption, and innovative peripherals. This product is part of the STM32F4 series, which is well-regarded for its advanced architecture based on the ARM Cortex-M4 processor with FPU (floating point unit), running at a frequency of up to 100 MHz.

Key Features

• Core: ARM Cortex-M4 with FPU and frequency up to 100 MHz
• Memory: 1.5 Mbytes of Flash memory and 320 Kbytes of SRAM
• Performance: 125 DMIPS/339 EEMBC CoreMark score at 100 MHz
• Power Efficiency: Low-power modes including Sleep, Stop, and Standby
• ADC: Three 12-bit ADCs with 2.4 MSPS
• Communication Interfaces: I2C, SPI, USART, and USB OTG FS
• Advanced Peripherals: LCD parallel interface, True Random Number Generator (TRNG)
• Package: LQFP64 package

Advanced Connectivity

The STM32F413RHT6 comes with multiple communication interfaces, including I2C, SPI, USART, and USB OTG FS, allowing for versatile connectivity options. This makes it suitable for a wide range of applications that require connections to various peripherals and systems.

Robust Peripheral Set

This MCU boasts a comprehensive set of peripherals that are designed to support complex and demanding applications. The inclusion of a True Random Number Generator enhances security-related functions, while the LCD parallel interface allows for direct connection to graphical displays.

Applications

The STM32F413RHT6 is ideal for a variety of applications, including industrial control systems, Internet of Things (IoT) devices, healthcare equipment, and consumer electronics. Its performance and feature set cater to the needs of developers looking for a reliable and powerful microcontroller.

Development and Support

STMicroelectronics provides extensive support for the STM32F413RHT6 through its STM32Cube software development kit (SDK), which includes HAL (Hardware Abstraction Layer) libraries, middleware components, and examples to accelerate the development process. Additionally, the STM32 ecosystem is supported by a wide range of development boards and software tools.
