Products specifications

Category Integrated Circuits (ICs)>Embedded - Microcontrollers
Mfr STMicroelectronics
Series STM32F7
Package Tray
Core Processor ARM® Cortex®-M7
Core Size 32-Bit Single-Core
Speed 216MHz
Connectivity CANbus, EBI/EMI, Ethernet, I2C, IrDA, LINbus, MMC/SD/SDIO, QSPI, SAI, SPDIF, SPI, UART/USART, USB OTG
Peripherals Brown-out Detect/Reset, DMA, I2S, LCD, POR, PWM, WDT
Number of I/O 140
Program Memory Size 2MB (2M x 8)
Program Memory Type FLASH
RAM Size 512K x 8
Supply Voltage - Operating 1.7V ~ 3.6V
Data Converters A/D 24x12b; D/A 2x12b
Oscillator Type Internal
Temperature Range - Operating -40°C ~ 85°C (TA)
Mounting SMD (SMT)
Package / Case 176-LQFP
Supplier Device Package 176-LQFP (24x24)
Base Product Number STM32F769
Other Names 497-16649
Standard Package 40
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN 3A991A2
HTSUS 8542.31.0001
Win Source Part Number 1262710-STM32F769IIT6
Ultra Librarian 3D Model Ultra Librarian STM32F769IIT6 CAD Model

Description

The STM32F769IIT6 is a high-performance microcontroller from STMicroelectronics, designed to offer the best solutions for demanding applications. It is part of the STM32F7 series, which is STMicroelectronics' advanced line of ARM® Cortex®-M7 based microcontrollers. This product features a range of enhanced I/Os and peripherals, making it ideal for a wide range of applications, including industrial control, medical equipment, consumer electronics, and IoT devices.

Key Features

  • Core: ARM® Cortex®-M7 processor, running at frequencies of up to 216MHz.
  • Memory: 2Mbytes of Flash memory and 512+16+4 Kbytes of RAM.
  • Graphics: STM32 Chrom-ART Accelerator™ for enhanced graphic operations, LCD-TFT controller, and MIPI® DSI host controller.
  • Audio: Dedicated audio PLLs and two full-duplex I²S interfaces.
  • Rich Connectivity: USB OTG HS/FS, Ethernet, SDMMC, CAN, USART, SPI, I2C, and more.
  • Advanced Peripherals: Multiple timers, ADC, DAC, and advanced-control PWM timers.
  • Security: Hardware cryptographic acceleration and a true random number generator for advanced security.
  • Power Efficiency: Various power-saving modes including a flexible power control system to optimize power consumption.

Applications

The STM32F769IIT6's versatile feature set enables it to be the core component in a multitude of application areas. In industrial markets, it can be used for automation systems, PLCs, robotics, and complex IoT systems. In the consumer space, it can power innovative user interfaces for smart home devices, wearables, and gaming consoles. For medical applications, its precision and reliability support advanced medical devices and monitoring systems. Furthermore, the microcontroller's capabilities make it suitable for advanced audio and graphical processing tasks required in multimedia applications.

Development Support

STMicroelectronics provides extensive support for the STM32F769IIT6 through their STM32Cube software ecosystem, which includes a comprehensive set of tools for developing and debugging. Additionally, a wide range of development boards and kits are available to accelerate the design and development process for engineers and makers.
