STN2NF10 N-Channel MOSFET by STMicroelectronics

The STN2NF10 is a high-performance N-Channel MOSFET brought to you by STMicroelectronics, a leader in semiconductor solutions. This MOSFET is designed to provide efficient power management and switching with low on-state resistance and high switching speed, making it an excellent choice for a variety of applications.

Key Features

• Device Type: N-Channel MOSFET
• Drain-Source Voltage (V<sub>DS): 100V
• Continuous Drain Current (I<sub>D): 2A
• Power Dissipation (P<sub>D): 25W
• On-State Resistance (R<sub>DS(on)): Typically 0.3Ω
• Gate Threshold Voltage (V<sub>GS(th)): 2V to 4V
• Fast Switching Speed: Ensures efficient operation in high-speed circuits.
• Low Gate Charge: Reduces power loss during switching.

Applications

The STN2NF10 is suitable for a wide range of applications, including:

• Switch Mode Power Supplies (SMPS)
• DC-DC Converters
• Motor Control
• Power Management Functions
• Load Switch
• Automotive Applications

Quality and Reliability

STMicroelectronics is committed to delivering high-quality products. The STN2NF10 is built to meet rigorous standards, ensuring reliability and performance in even the most demanding environments. It is designed to withstand high energy pulses in the avalanche and commutation modes, further adding to its robustness.

Package and Environmental Compliance

The STN2NF10 is available in a compact SOT-223 package, which is ideal for space-constrained applications. It is also compliant with RoHS and Halogen-Free standards, making it an environmentally friendly choice for designers looking to create eco-conscious electronic products.

With its combination of efficiency, speed, and reliability, the STN2NF10 N-Channel MOSFET from STMicroelectronics is an excellent component for designers who require a high-quality switching solution.
