Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Type Linear
Topology Shift Register
Internal Switch(s) Yes
Number of Outputs 16
Operating Input Voltage(Min) 3V
Maximum Supply Voltage 5.5V
Output Voltage 20V
Channel Output Current 100mA
Frequency 30MHz
Temperature Range - Operating -40°C to 125°C (TA)
Mounting SMD (SMT)
Case / Package 24-SOP
Win Source Part Number 106924-STP16CPS05MTR
Family Name STP16CPS05
Introduction Date July 28, 2006
ECCN EAR99
Country of Origin Malaysia
Halogen Free Not Compliant
Estimated EOL Date 2025
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian STP16CPS05MTR CAD Model

Description

STP16CPS05MTR LED Driver IC by STMicroelectronics

The STP16CPS05MTR is a sophisticated LED driver integrated circuit (IC) produced by STMicroelectronics, designed to provide a seamless and efficient solution for driving LEDs in a variety of applications. This driver IC is part of the STP16CPS05 series, which is known for its reliability and performance in LED lighting systems.

With a 16-bit constant current LED sink driver, the STP16CPS05MTR ensures consistent illumination by delivering a stable current to each LED, which is essential for maintaining uniform brightness and color accuracy. The device is capable of handling a wide range of input voltages, making it versatile for different LED configurations and power supplies.

The STP16CPS05MTR also features an integrated 3.3V voltage regulator, which simplifies the power supply design by allowing the IC to operate from a single supply voltage. This is particularly beneficial for compact applications where space is at a premium, and efficiency is crucial.

One of the standout features of the STP16CPS05MTR is its error detection functionality. The IC can detect open and short-circuit conditions on the LED outputs, which helps in identifying and preventing potential issues in the LED array. This not only enhances the safety of the lighting system but also contributes to its longevity.

The device supports a wide range of dimming capabilities, enabling precise control over the brightness levels through pulse width modulation (PWM). This makes the STP16CPS05MTR an excellent choice for applications where adjustable lighting is necessary, such as architectural lighting, signage, and decorative illumination.

For ease of integration, the STP16CPS05MTR comes in a 24-pin TSSOP package, which is suitable for automated assembly processes and provides a compact footprint for space-constrained designs. The IC can be cascaded, allowing multiple devices to be connected in series for larger LED arrays without the need for additional controllers.

In summary, the STP16CPS05MTR from STMicroelectronics is a high-performance LED driver that offers consistent current regulation, error detection, dimming capabilities, and a compact form factor, making it an ideal choice for a wide range of LED lighting applications.
