STP265N6F6AG - A High-Performance MOSFET by STMicroelectronics

The STP265N6F6AG is a state-of-the-art N-channel MOSFET produced by STMicroelectronics, a global leader in semiconductor solutions. This power MOSFET is designed to deliver high efficiency and performance in a wide range of applications, including power supplies, motor control, automotive systems, and other high-power switching applications.

Key Features

• Advanced Technology: The STP265N6F6AG utilizes STMicroelectronics' latest MDmesh™ K5 technology, which combines extremely low on-resistance with a high dv/dt capability, ensuring optimal performance in fast-switching applications.
• High Current Capability: With a continuous drain current (ID) rating of 210 A, this MOSFET can handle high current loads, making it suitable for demanding environments.
• Low On-Resistance: The device boasts an impressively low on-resistance (RDS(on)) of just 6 mΩ (max), which minimizes conduction losses and improves overall efficiency.
• High Voltage Tolerance: The STP265N6F6AG can withstand drain-source voltages (VDS) up to 60 V, providing a robust solution for a variety of circuit designs.
• Enhanced Thermal Performance: Encased in a highly efficient H2PAK-6 package, the MOSFET offers excellent thermal performance, ensuring reliability even under high temperature operating conditions.

Applications

• Switch Mode Power Supplies (SMPS)
• DC/DC converters
• Motor Control Systems
• Automotive Applications
• Power Management Solutions

Reliability and Quality

The STP265N6F6AG is designed with reliability in mind. It is rigorously tested and qualified to meet the high standards of STMicroelectronics, ensuring long-term performance and stability. The MOSFET is also compliant with the RoHS directive, which restricts the use of certain hazardous substances in electronic equipment.

In summary, the STP265N6F6AG from STMicroelectronics is a powerful and efficient N-channel MOSFET that offers designers a superior solution for high-power and high-efficiency applications. Its advanced features and robust package design make it a top choice for engineers looking to improve system performance and reliability.
