The STP26NM60N is a high performance N-Channel MOSFET produced by STMicroelectronics, a leader in semiconductor solutions. This MOSFET is designed to deliver efficient power conversion with low on-state resistance and fast switching performance. It is an ideal choice for a wide range of applications, including switch-mode power supplies (SMPS), lighting, DC-AC inverters, and motor control.

Key Features

• Voltage Rating: The STP26NM60N is rated for a drain-source voltage (V<sub>DS) of 600V, making it suitable for high voltage applications.
• Current Handling: It can handle continuous drain current (I<sub>D) up to 20A, ensuring robust performance for heavy-duty operations.
• Low R<sub>DS(on): With an on-state resistance as low as 0.165Ω, it provides high efficiency and minimizes power losses during operation.
• Fast Switching: The device features a fast switching speed, which is crucial for reducing switching losses and improving power supply efficiency.
• High dv/dt Capability: The MOSFET can withstand high voltage changes over time (dv/dt), making it reliable in applications with high switching frequencies.

Advanced Technology

STMicroelectronics has integrated their state-of-the-art MDmesh™ II technology into the STP26NM60N, which combines a vertical structure with a strip layout to achieve a better trade-off between on-resistance and gate charge. This results in superior switching performance and lower conduction losses.

Applications

• Power Supply Units (PSUs)
• LED Lighting Systems
• Solar Inverters
• Uninterruptible Power Supplies (UPS)
• High Performance Drives
• Welding Equipment

Package and Environmental Compliance

The STP26NM60N is available in a TO-220 package, which is widely used and easy to mount on printed circuit boards. Additionally, STMicroelectronics is committed to environmental sustainability, and the STP26NM60N is designed to meet RoHS and other environmental regulations, reducing the environmental impact.
