The STP36NF06 is a robust N-channel enhancement-mode Field Effect Transistor (FET) produced by STMicroelectronics. This power MOSFET is a part of ST's STripFET™ II series, which is renowned for its high efficiency and low on-state resistance. The device is designed to handle high current and voltage, making it suitable for a wide range of applications, including power supplies, motor control, and general-purpose switching.

Key Features

• Drain-source Voltage (V<sub>DS): 60V
• Continuous Drain Current (I<sub>D): 30A
• Low Threshold Voltage: This feature allows for the device to be driven at lower gate voltages, enhancing its efficiency in low-voltage applications.
• Low On-state Resistance (R<sub>DS(on)): 0.036Ω typ. at V<sub>GS = 10V, I<sub>D = 18A, which minimizes power loss and improves efficiency.
• 100% Avalanche Tested: Guarantees robust performance and reliability.
• High Thermal Performance: With an excellent ability to dissipate heat, the STP36NF06 is capable of maintaining stability even under high current conditions.

Applications

The STP36NF06's versatility allows it to be used in a variety of applications such as:

• Switch Mode Power Supplies (SMPS)
• High-efficiency DC-DC converters
• Motor control circuits
• Power management functions
• Automotive and industrial applications requiring high current and voltage handling capabilities

Quality and Reliability

STMicroelectronics is committed to delivering high-quality products. The STP36NF06 is no exception, as it is manufactured with state-of-the-art technology for dependable performance. Its robust design ensures a long operational life even in the most demanding conditions.

Environmental Compliance

The STP36NF06 is compliant with RoHS (Restriction of Hazardous Substances) and is designed to meet the environmental standards, ensuring a minimal ecological footprint.
