The STP55NF06FP is a robust N-channel MOSFET from STMicroelectronics, renowned for its high efficiency and performance in a wide range of electronic applications. This power MOSFET is designed using STMicroelectronics' unique STripFET™ process, which provides excellent on-state resistance and switching performance, making it suitable for high-power switching applications and power management tasks.

Key Features

• High Current Capability: The STP55NF06FP can handle continuous drain currents up to 55A, making it ideal for high current applications.
• Low On-Resistance: With a typical on-resistance of just 0.015Ω, this MOSFET ensures high efficiency and minimal voltage drop during operation.
• High Switching Speed: The device features fast switching speed, which enhances performance in applications requiring frequent on-off cycles.
• High Voltage Threshold: The MOSFET has a maximum drain-source voltage (V_DS) of 60V, providing a good safety margin for a variety of applications.
• 100% Avalanche Tested: Each unit is tested for guaranteed performance in applications where inductive loads may produce unclamped inductive switching (UIS).

Applications

The STP55NF06FP is versatile and can be used in a variety of applications, including:

• Switch mode power supplies (SMPS)
• DC-DC converters
• Motor drivers
• Automotive applications
• Power management systems

Package and Mounting

The STP55NF06FP is available in a TO-220FP package, which is designed for through-hole mounting. The TO-220FP package enhances thermal performance and is suitable for commercial-grade applications.

Quality and Reliability

STMicroelectronics is committed to delivering high-quality products. The STP55NF06FP is no exception and is manufactured to meet the highest industry standards for performance and reliability.
