STPS20H100CG-TR - High Voltage Power Schottky Rectifier

The STPS20H100CG-TR from STMicroelectronics is a robust and high-efficiency power Schottky rectifier designed for high-frequency power supplies and other power switching applications. This device is tailored to meet the stringent requirements of modern electronic equipment, offering a combination of low forward voltage drop and high surge current capability.

Key Features

• High Junction Temperature: Capable of operating at a junction temperature of up to 175°C, the STPS20H100CG-TR ensures reliability in even the most demanding thermal environments.
• Low Forward Voltage Drop: With a low forward voltage drop, this rectifier enhances system efficiency, which is particularly beneficial in applications where power loss is critical.
• High Surge Capability: Designed to withstand high surge currents, this device is ideal for applications that experience frequent power surges, ensuring long-term reliability and performance.
• Dual Center Tap Configuration: The dual center tap configuration of the STPS20H100CG-TR allows for flexibility in the design of power circuits, making it suitable for complex power supply systems.
• TO-220AB Package: Enclosed in a TO-220AB package, the rectifier provides a compact solution with easy mounting and excellent thermal performance.

Applications

The STPS20H100CG-TR is ideal for a wide range of applications, including:

• Switch Mode Power Supplies (SMPS)
• High-frequency DC/DC converters
• Free-Wheeling diodes
• Reverse battery protection
• OR-ing diode in redundant power systems

Product Summary

The STPS20H100CG-TR Schottky rectifier is a high-performance solution that combines efficiency with reliability. With its high surge current capability and low forward voltage drop, it's designed to meet the needs of modern high-density power systems. The device's robustness and versatility make it a top choice for engineers looking for a rectifier that can handle the challenges of high-speed power applications.
