STPS30H60CKY-TR - Power Schottky Rectifier by STMicroelectronics

The STPS30H60CKY-TR is a robust and efficient power Schottky rectifier designed and manufactured by STMicroelectronics, a global leader in semiconductor solutions. This high-performance component is engineered to handle high current and voltage with minimal power loss, making it an ideal choice for a wide range of power conversion and management applications.

Key Features

• Dual Center Tap Schottky Rectifier: The STPS30H60CKY-TR is configured as a dual center tap Schottky rectifier, which is commonly used in high-frequency power supplies and as freewheeling diodes.
• High Junction Temperature: With a maximum operating junction temperature of 175°C, this device can withstand high thermal conditions, ensuring reliability and longevity in harsh environments.
• Low Forward Voltage Drop: The low forward voltage drop (VF) characteristic of the STPS30H60CKY-TR minimizes conduction losses, thereby improving energy efficiency in the application it is used.
• Avalanche Capability: This rectifier has the ability to handle high energy pulses in avalanche mode, providing an additional layer of protection against voltage transients.
• High Surge Current Capability: The device is capable of supporting high surge currents, making it suitable for applications that experience frequent current spikes.

Applications

• Switch Mode Power Supplies (SMPS)
• High-frequency DC/DC converters
• Power factor correction circuits
• Reverse battery protection
• Automotive applications

Package and Quality

The STPS30H60CKY-TR is encapsulated in an insulated TO-247 package, which provides excellent thermal resistance and mechanical durability. This package is widely accepted in high power and high thermal applications. Additionally, STMicroelectronics is committed to delivering high-quality products, and this rectifier is no exception, complying with the stringent industry standards for performance and reliability.

With its combination of efficiency, durability, and high-temperature performance, the STPS30H60CKY-TR is a superior choice for designers looking to enhance the performance of their power management systems while maintaining a compact and energy-efficient design.
