STPS41L60CG-TR - STMicroelectronics Schottky Rectifier

The STPS41L60CG-TR is a state-of-the-art Schottky rectifier designed and manufactured by STMicroelectronics, a leader in the semiconductor industry. This robust and efficient power Schottky diode is a critical component for modern power supply designs, offering a low forward voltage drop and high surge current capability. The device is packaged in a TO-263 (D2PAK) surface-mount package, making it suitable for compact and high-density circuit designs.

Key Features

• High Junction Temperature: With a maximum operating junction temperature of 150°C, the STPS41L60CG-TR can withstand high thermal conditions, making it reliable for various applications.
• Average Forward Current: It has an average forward current of 40A, which makes it capable of handling moderate to high power requirements efficiently.
• Low Forward Voltage Drop: The low forward voltage drop reduces power loss and improves efficiency, which is critical for energy-sensitive applications.
• High Surge Current Capability: Its ability to withstand high surge currents ensures reliability in applications subject to transient overcurrent conditions.
• Guard Ring for Enhanced Ruggedness and Long Term Reliability: The guard ring design provides protection against overvoltage, enhancing the robustness of the diode.

Applications

• Switching power supplies
• Power converters and inverters
• Free-wheeling diodes in motor control circuits
• Power management systems
• Automotive applications
• High-frequency rectification

The STPS41L60CG-TR is an excellent choice for designers looking for a high-performance Schottky rectifier that balances efficiency with thermal performance. Its low forward voltage drop and high surge current capability make it ideal for a wide range of applications, including high-frequency power supplies, automotive electronics, and industrial power management systems. With its robust design and reliability, the STPS41L60CG-TR is a testament to STMicroelectronics' commitment to delivering high-quality semiconductor solutions.
