STU7N60M2 Power MOSFET by STMicroelectronics

The STU7N60M2 is a robust and efficient power MOSFET designed and manufactured by STMicroelectronics, a global leader in semiconductor solutions. This high-performance transistor is part of STMicroelectronics' MDmesh™ M2 series, which is renowned for its excellent energy efficiency and thermal performance. The STU7N60M2 is particularly suited for a wide range of applications, including switch-mode power supplies (SMPS), lighting, DC-DC converters, and motor control circuits.

Key Features:

• High Voltage Capability: The STU7N60M2 is designed to handle high voltages, with a drain-source voltage (V<sub>DS) of up to 600V, making it suitable for various industrial and consumer applications that require high voltage operations.
• Low On-Resistance: With an on-resistance (R<sub>DS(on)) as low as 1.2 Ω, this MOSFET ensures minimal power loss during operation, contributing to the overall efficiency of the electronic system.
• High Current Rating: The device can support a continuous drain current (I<sub>D) of up to 7A, allowing it to handle significant power levels for a range of electrical tasks.
• Fast Switching Speed: The STU7N60M2 boasts a fast switching speed, which is essential for reducing switching losses in high-frequency power conversion systems.
• Low Gate Charge: A low gate charge (Q<sub>g) ensures that the MOSFET can be driven at lower voltages, which reduces the power needed to switch the device on and off, thereby saving energy.

Advanced Technology:

The MDmesh™ M2 technology incorporated in the STU7N60M2 utilizes a proprietary vertical structure that optimizes the device's on-state resistance and reduces gate charge, leading to superior switching performance and lower conduction losses. This technology is especially beneficial in applications where efficiency is paramount.

Applications:

The STU7N60M2 is versatile and can be used in various high-efficiency applications. Its robustness and reliability make it an ideal choice for:

• LED lighting systems
• High-efficiency SMPS
• Active Power Factor Correction (PFC) circuits
• Uninterruptible Power Supplies (UPS)
• Inverter circuits for renewable energy sources
• Automotive applications and motor drives

With its combination of high voltage capability, low on-resistance, and fast switching speeds, the STU7N60M2 from STMicroelectronics stands out as a power MOSFET that delivers both performance and reliability for designers and engineers looking to optimize their power management systems.
