Products specifications

Categories RF/IF and RFID
Features RF Mixer IC General Purpose Down Converter 695MHz ~ 960MHz 44-VFQFPN (7x7)
Manufacturer STMicroelectronics
Package Reel - TR
Part Status Not For New Designs
Mounting Surface Mount
Package 44-VFQFN Exposed Pad
Case / Package 44-VFQFPN (7x7)
Family Name STW82101
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Quantity per package 2500
Popularity High
Supply and Demand Status Balance
Win Source Part Number 898536-STW82101BTR
Ultra Librarian 3D Model Ultra Librarian STW82101BTR CAD Model

Description

The STW82101BTR is a cutting-edge RF synthesizer designed and manufactured by STMicroelectronics, a leader in the semiconductor industry. This device is part of a wide range of integrated circuits dedicated to RF applications. It is specifically tailored for use in telecommunications, consumer electronics, and industrial markets, where high performance and reliability are paramount.

With its high level of integration, the STW82101BTR offers a compact solution that reduces the need for external components. This not only saves space on the printed circuit board (PCB) but also helps in simplifying the design process and accelerating the time to market for products incorporating this synthesizer.

The STW82101BTR operates over a broad frequency range, making it an ideal choice for a variety of applications, including wireless communication systems, satellite communications, test equipment, and other RF-related fields. Its versatility is further enhanced by a programmable divider, which allows for fine-tuning of the output frequency to meet the specific requirements of different systems.

This synthesizer also features a low phase noise performance, which is critical for maintaining signal integrity in communication systems. The low noise characteristics ensure that the transmitted and received signals are clear and free from unwanted interference, leading to improved overall system performance.

The device is housed in a compact QFN package, which is designed for easy integration into a wide range of electronic assemblies. The STW82101BTR also incorporates power-saving features, making it suitable for battery-operated devices where power efficiency is crucial.

In summary, the STW82101BTR from STMicroelectronics is a high-performance RF synthesizer that offers designers a flexible, reliable, and efficient solution for their RF circuit designs. With its broad frequency range, low phase noise, and power efficiency, it stands out as a top choice for developers looking to create advanced RF systems.
