The TN2010H-6G-TR from STMicroelectronics is a cutting-edge thyristor, also known as a silicon-controlled rectifier (SCR), designed to manage and control high power in a wide range of applications. This particular component is part of STMicroelectronics' high-temperature Thyristor series, which is capable of operating in environments with temperatures up to 150°C.

Key Features

• High Junction Temperature: The device features a maximum operating junction temperature of 150°C, making it suitable for high-temperature applications.
• High Surge Capability: With a non-repetitive surge peak on-state current (ITSM) of 200 A, the TN2010H-6G-TR can handle high surge currents, ensuring robust performance during transient conditions.
• Gate Trigger Current: A low gate trigger current (IGT) of less than 15 mA simplifies the drive requirements and allows for the use of less powerful gate drive circuits.
• Repetitive Peak Off-state Voltage: A VDRM/VRRM of 600 V provides a good margin for applications with high off-state voltage requirements.
• On-state RMS Current: The device supports an on-state RMS current of 20 A, enabling it to handle significant power during normal operation.

Applications

The TN2010H-6G-TR is ideal for a variety of applications where power control is essential. Its robustness and high-temperature performance make it particularly well-suited for:

• Motor control circuits
• Overvoltage crowbar protection
• Capacitive discharge ignitions
• Voltage regulation circuits
• Controlled rectifier bridges

Package and Availability

STMicroelectronics provides the TN2010H-6G-TR in a surface-mount DPAK (TO-252) package, which is widely used in the industry and is suited for automated PCB assembly processes. The product is available in tape and reel format, denoted by the '-TR' suffix, facilitating efficient handling and manufacturing.

With its robust performance and versatility, the TN2010H-6G-TR from STMicroelectronics represents a reliable solution for designers who require a high-performance thyristor for their high-power control applications.
