Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer STMicroelectronics
Packaging Tube
Triac Type Alternistor - Snubberless
Voltage - Off State 800V
Current - On State (It (RMS)) (Maximum) 40A
Voltage - Gate Trigger (Vgt) (Maximum) 1.5V
Current - Non Rep. Surge 50, 60Hz (Itsm) 350A, 370A
Current - Gate Trigger (Igt) (Maximum) 200mA
Current - Hold (Ih) (Maximum) 50mA
Configuration Single
Operating Temperature Range -40°C ~ 125°C (TJ)
Mounting Style Through Hole
Package TOP-3
Manufacturer Package TOP3
Win Source Part Number 797826-TPDV840RG
Popularity Medium
Supply and Demand Status Limited
Family Name TPDV840
Introduction Date August 21, 1995
ECCN EAR99
Country of Origin Philippines
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian TPDV840RG CAD Model

Description

The TPDV840RG is a high-performance triac manufactured by STMicroelectronics, designed for use in AC load switching applications. This device is well-suited for a wide range of applications requiring high bidirectional transient and blocking voltage capability and high thermal cycling performance. The TPDV840RG is commonly employed in applications such as motor control circuits, heater controls, and other power switching applications where efficiency and reliability are crucial.

Key Features

  • Voltage Capability: The TPDV840RG is capable of handling voltages up to 800V, making it suitable for a variety of AC power applications.
  • Current Rating: With an on-state RMS current of 40A, this triac can manage significant power levels, ensuring robust performance in demanding situations.
  • High Commutation Performance: The triac offers high commutation capabilities, which is essential for ensuring stable operation in inductive load scenarios.
  • Gate Trigger Current: A low gate trigger current (IGT) makes the TPDV840RG easy to drive with simple gate drive circuits.
  • Package: Housed in a RD91 package, the TPDV840RG is designed for optimal heat dissipation and robustness, ensuring long-term reliability.

Applications

  • Motor control for home appliances
  • Heating elements regulation
  • Industrial process control
  • Lighting control systems

Product Advantages

The TPDV840RG from STMicroelectronics stands out due to its high voltage and current handling capabilities, combined with high commutation performance. This makes it an excellent choice for applications that require frequent switching of high AC loads. Its low gate trigger current allows for simplified control circuitry, reducing overall system complexity and cost. The RD91 package is designed to offer superior thermal performance, ensuring that the device can handle high temperature and power cycling conditions without degradation of its characteristics over time.

Environmental and Quality Certifications

STMicroelectronics is committed to environmental sustainability and quality. The TPDV840RG complies with various international standards, ensuring that it meets the rigorous demands of electronic component certifications for safety, reliability, and environmental impact.
