Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Reel - TR
Status Active
Type General Purpose
Number of Elements 2
Output Type Push-Pull
Supply Voltage - Operating 1.8 V to 5 V
Voltage - Input Offset (Max) 8mV @ 5V
Current - Input Bias (Max) 0.16μA @ 5V
Current - Quiescent (Max) 90μA
CMRR, PSRR (Typ) 79dB CMRR
Propagation Delay (Max) 105ns
Temperature Range - Operating -40°C to 125°C
Mounting SMD (SMT)
Case / Package 8-SO
Win Source Part Number 1114305-TS3022IDT
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian TS3022IDT CAD Model

Description

Product Overview: TS3022IDT Precision Operational Amplifier

The TS3022IDT is a high-precision operational amplifier from STMicroelectronics, renowned for its exceptional accuracy and low power consumption. This operational amplifier is a perfect fit for a wide array of applications, including industrial control systems, sensor interfaces, and professional audio equipment.

Key Features

  • Low Offset Voltage: The TS3022IDT boasts an ultra-low input offset voltage, which significantly enhances measurement accuracy and stability over time and temperature variations.
  • Low Noise: With its low noise density, this op-amp minimizes the impact of electrical noise on signal integrity, making it ideal for high-fidelity audio applications and precision instrumentation.
  • High Gain Bandwidth Product: The device offers a high gain bandwidth product, ensuring ample bandwidth for a variety of applications without compromising the gain.
  • Rail-to-Rail Output: The TS3022IDT can swing its output voltage from rail to rail, maximizing the dynamic range in single-supply operations and simplifying power supply design.
  • Wide Supply Voltage Range: It operates over a broad supply voltage range, accommodating various application requirements and simplifying integration into existing designs.
  • Low Power Consumption: The op-amp is designed for low power consumption, making it suitable for battery-powered devices and energy-efficient applications.
  • Extended Temperature Range: It is capable of operating over an extended temperature range, ensuring reliable performance in harsh environments.

Applications

The versatility of the TS3022IDT allows it to be used in numerous applications, ranging from precision data acquisition systems, medical instruments, and automotive electronics to battery-operated devices, power supply control, and analog filters. Its robust design and high precision make it an excellent choice for any application requiring a high-quality operational amplifier.

Package and Quality

Packaged in a compact SO-8, the TS3022IDT is designed for space-constrained applications. STMicroelectronics' commitment to quality ensures that this operational amplifier meets the highest industry standards for performance and reliability.
