Products specifications

Categories Integrated Circuits
Manufacturer STMicroelectronics
Packaging Tube/Rail
Status Active
Type with Voltage Reference
Number of Elements 2
Supply Voltage - Operating 2 V to 36 V, ±1 V to 18 V
Voltage - Input Offset (Max) 5mV @ 5V
Current - Input Bias (Max) 0.25μA @ 5V
Current - Output (Typ) 20mA @ 5V
Current - Quiescent (Max) 2.5mA
Temperature Range - Operating -40°C to 105°C
Mounting SMD (SMT)
Case / Package 8-SO
Win Source Part Number 035352-TSM109ID
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian TSM109ID CAD Model

Description

STMicroelectronics TSM109ID Dual Operational Amplifier

The TSM109ID from STMicroelectronics is a highly-integrated circuit designed to provide a dual operational amplifier solution for a wide range of applications. This precision op-amp is particularly suitable for applications requiring low power consumption and a wide bandwidth. With its dual amplifiers, the TSM109ID is an excellent choice for audio processing, sensor signal conditioning, active filtering, and many other applications where dual operational amplifiers are required.

Featuring a low input bias current, the TSM109ID ensures high-accuracy signal processing, making it ideal for applications that demand precise measurements. The device also offers a low input offset voltage, which minimizes errors in signal amplification, ensuring the integrity of the output signal.

The TSM109ID operates within a supply voltage range of 3V to 30V, or ±1.5V to ±15V in split supply applications, providing the flexibility needed to support both low and high-voltage systems. This wide range of operating voltages makes the TSM109ID adaptable to various power environments without sacrificing performance.

With a large output voltage swing, the TSM109ID is capable of driving a variety of loads while maintaining linearity and low distortion. This feature is particularly valuable in audio applications where maintaining signal fidelity is crucial. Additionally, the device is designed with short-circuit protection, enhancing its reliability and robustness in harsh electrical environments.

The TSM109ID is available in an 8-pin SOIC package, which is compact and suitable for space-constrained applications. Its small footprint allows for efficient use of PCB real estate, making it a practical choice for dense circuit designs.

In summary, the STMicroelectronics TSM109ID is a versatile dual operational amplifier that offers low power consumption, wide bandwidth, and high precision. Its robust feature set and flexible operating voltage range make it an excellent choice for a multitude of electronic applications requiring reliable and efficient signal amplification.
