BZD27C13P Vaishali Semiconductor
Same model may have multiple batches, images only for reference.

BZD27C13P

Part No BZD27C13P
Manufacturer Taiwan Semiconductor
Catalog Diodes - Zener - Single
Description SUB SMA, 1000MW, 6%, ZENER DIODE
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Zener - Single Zener Diodes
Mfr Taiwan Semiconductor
Package Tape & Reel
Product Status Active
Voltage - Zener (Nom) (Vz) 13.25 V
Tolerance ±6.42%
Power - Max 1 W
Impedance (Max) (Zzt) 10 Ohms
Current - Reverse Leakage @ Vr 2 µA @ 10 V
Voltage - Forward (Vf) (Max) @ If 1.2 V @ 200 mA
Temperature Range - Operating -55°C ~ 175°C (TJ)
Mounting Type Surface Mount
Package / Case SOD-123
Supplier Device Package Sub SMA
Base Product Number BZD27
Standard Package 10,000 pcs
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0050
Win Source Part Number 574270-BZD27C13P
Ultra Librarian 3D Model Ultra Librarian BZD27C13P CAD Model

Description

The 574270-BZD27C13P is a single zener diode with a voltage rating of 13.25V and a power rating of 1W.

  • Voltage: 13.25V
  • Power: 1W
  • Tolerance: ±6.42%
  • Maximum Impedance: 10 Ohms
  • Mounting: surface mountable
  • Package: tape & reel
  • Quantity: 10,000 pieces
  • Temperature Range: -55°C to 175°C
  • Product Status: active
  • Manufacturer: Taiwan Semiconductor
