SRF10200 MIC GROUP RECTIFIERS
Same model may have multiple batches, images only for reference.

SRF10200

Part No SRF10200
Manufacturer Taiwan Semiconductor
Catalog Diodes, Rectifiers - Single
Description DIODE SCHOTTKY 200V 10A ITO220AB
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Single Diodes
Mfr Taiwan Semiconductor
Package Tube
Product Status Active
Technology Schottky
Voltage - DC Reverse (Vr) (Max) 200 V
Current - Average Rectified (Io) 10A
Voltage - Forward (Vf) (Max) @ If 1 V @ 5 A
Speed Fast Recovery =< 500ns, > 200mA (Io)
Current - Reverse Leakage @ Vr 100 µA @ 200 V
Mounting Type Through Hole
Package / Case TO-220-3 Full Pack, Isolated Tab
Supplier Device Package ITO-220AB
Operating Temperature - Junction -55°C ~ 150°C
Base Product Number SRF10200
Standard Package 50 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 727197-SRF10200
Ultra Librarian 3D Model Ultra Librarian SRF10200 CAD Model

Description

The 727197-SRF10200 is a Schottky diode designed for fast recovery applications.

  • Maximum DC Reverse Voltage: 200V
  • Average Rectified Current: 10A
  • Forward Voltage Drop: 1V @ 5A
  • Reverse Leakage Current: 100µA @ maximum reverse voltage
  • Package: TO-220-3 full pack
  • Feature: isolated tab
  • Operating Temperature: -55°C to 150°C
  • Product Status: active
  • Manufacturer: Taiwan Semiconductor
