The MM3Z3V6CW is a surface-mount Zener diode manufactured by Tak Cheong Electronics. It is designed for voltage regulation and transient voltage suppression in various electronic circuits.

Applications:

• Voltage regulation in consumer electronics.
• Transient voltage suppression in portable devices.
• Protection circuits for sensitive components.
• Clipping and clamping circuits.
• Electronic ballast.

Features:

• Surface-mount package for automated assembly.
• Low profile design.
• High surge current capability.
• Excellent clamping capability.
• Zener voltage of 3.6V.
• Lead-free finish, RoHS compliant.

Benefits:

• Provides stable voltage regulation for sensitive circuits.
• Protects circuits from voltage spikes and surges.
• Reduces board space requirements due to its small size.
• Increases reliability of electronic devices.
• Complies with environmental regulations.

Additional Details:

The MM3Z3V6CW has a power dissipation of approximately 200mW. Its operating temperature range is typically from -65°C to +150°C. The device is typically packaged in a SOD-323 package. It is commonly used to protect sensitive integrated circuits from overvoltage conditions, ensuring the reliable operation of electronic equipment.

The Zener voltage is tested under specific conditions. It's critical to review the datasheet provided by Tak Cheong Electronics for precise electrical characteristics and application guidelines. Correct polarity during installation is essential for proper function and prevention of damage.

The surface mount design allows for easy integration into automated manufacturing processes, helping reduce production costs. Furthermore, its robust design makes it suitable for use in harsh industrial and automotive environments.
