The TSL0808RA-330K1R4-PF is a high-frequency multilayer ceramic inductor manufactured by TDK Corporation. Designed for use in a variety of RF and high-frequency applications, this component provides a stable inductance value and low losses. Its small size and robust construction make it ideal for integration into compact electronic devices.

Applications:


• RF filters in mobile communication devices.

• Impedance matching circuits.

• Wireless LAN (WLAN) applications.

• Bluetooth modules.

• Voltage-controlled oscillators (VCOs).

Features:


• Multilayer ceramic construction for high stability.

• Compact 0808 case size.

• High self-resonant frequency (SRF).

• Excellent Q-factor for low losses.

• Inductance value of 330nH.

• RoHS compliant.

Benefits:


• Improved RF signal quality due to low losses.

• Stable performance in high-frequency circuits.

• Space-saving design for compact devices.

• Reduced power consumption in wireless applications.

• Reliable operation under various environmental conditions.

Additional Details:

The TSL0808RA-330K1R4-PF has a nominal inductance of 330 nH with a tolerance of ±10%. The 0808 form factor defines its physical dimensions, making it suitable for dense circuit board layouts. The multilayer ceramic construction provides excellent stability and minimizes parasitic effects. The high self-resonant frequency (SRF) ensures that the inductor maintains its performance even at high frequencies. The rated current is approximately 100mA. The inductor is designed to withstand reflow soldering temperatures, compatible with modern manufacturing processes. Its operating temperature range typically spans from -55°C to +125°C. The TSL0808RA series is known for its high Q-factor, minimizing energy losses in RF applications. The ‘PF’ suffix indicates that the component is lead-free and RoHS compliant, meeting environmental standards. This component is used to ensure efficient and reliable signal transmission and reception in wireless devices. Its stable electrical characteristics ensure consistent circuit performance over a wide range of operating conditions.
