TSL1112RA-103JR14-PF TDK Corporation TSL1112RA-103JR14-PF Real Image TSL1112RA-103JR14-PF real image
Same model may have multiple batches, images only for reference.
TSL1112RA-103JR14-PF TDK Corporation TSL1112RA-103JR14-PF Real Image TSL1112RA-103JR14-PF real image
TSL1112RA-103JR14-PF TDK Corporation TSL1112RA-103JR14-PF Real Image TSL1112RA-103JR14-PF real image
Same model may have multiple batches, images only for reference.

TSL1112RA-103JR14-PF

Part No TSL1112RA-103JR14-PF
Manufacturer TDK Corporation
Catalog Fixed Inductors
Description FIXED IND 10MH 140MA 18 OHM TH
Datasheet
TSL1112RA-103JR14-PF Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Inductors, Coils, Chokes
Manufacturer TDK Corporation
Packaging AMMO PACKAGE
Status Obsolete(EOL)
Inductance 10mH
Tolerance ±5%
Current Rating 140mA
Current - Saturation 170mA
DC Resistance (DCR) 18 Ohm Max
Q @ Freq 30 @ 79.6kHz
Frequency - Self Resonant 380kHz
Temperature Range - Operating -20°C to 85°C
Frequency - Test 1kHz
Mounting Through Hole
Height - Seated (Max) 0.492" (12.50mm)
Win Source Part Number 054482-TSL1112RA-103JR14-PF
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name TSL
Introduction Date June 25, 1999
ECCN EAR99
Estimated EOL Date Obsolete
Ultra Librarian 3D Model Ultra Librarian TSL1112RA-103JR14-PF CAD Model

Description

The TSL1112RA-103JR14-PF is an inductor coil choke manufactured by TDK Corporation.

  • Current Rating: 140mA
  • Inductance: 10mH
  • Supply and Demand Status: Balanced
  • Temperature Range: -20°C to 85°C
  • Tolerance: ±5%
  • DC Resistance (DCR): 18 Ohm Max
  • Frequency - Self-Resonant: 380kHz
