TE Connectivity AMP Connectors 763567-4-103239-0 is a header, breakaway connector that belongs to the AMPMODU Mod II series. The connector comes in bulk packaging and has 40 positions.

• Series: AMPMODU Mod II
• Packaging: Bulk
• Positions: 40
• Mounting Style: Through-hole
• Operating Temperature Range: -65°C ~ 105°C
• Contact Type: Male pin
• Positions Loaded: All
• Rows: 1
• Termination: Solder
• Fastening Type: Push-pull
• Contact Material: Copper alloy
• Current Rating: 3A
• Flammability Rating: UL94 V-0
• Insulation Material: Thermoplastic
• Board-to-Board/Cable Style: Board-to-board or cable
• Pitch-Mating: 0.100" (2.54mm)
• Contact Finish-Mating: Gold
• Contact Finish-Mating Thickness: 30μin (0.76μm)
• Contact Finish-Post: Tin-lead
• Contact Finish-Post Thickness: 100μin (2.54μm)
• Family: 103239
• Shrouding: Unshrouded
• Contact Shape: Square
• Overall Contact Length: 0.440" (11.18mm)
• Insulation Height: 0.090" (2.29mm)
• Contact Length-Mating: 0.230" (5.84mm)
• Contact Length-Post: 0.120" (3.05mm)
• Alternative Parts: MTLW-140-08-T-S-269, MTLW-140-07-G-S-210, MTLW-140-05-H-S-210
• ECCN: EAR99
• Popularity: Medium
• Supply: Limited
