The TE Connectivity AMP Connectors 1332498-5-146257-4 is a male pin header connector with 8 positions and 2 rows.

• Mounting: through-hole
• Pitch-Mating: 0.100" (2.54mm)
• Current Rating: 3A
• Contact Finish: gold
• Finish Thickness: 30.0µin (0.76µm)
• Contact Material: copper alloy
• Contact Type: male pin
• Temperature Range: -65°C to 105°C
• Insulation Material: liquid crystal polymer (LCP)
• Flammability Rating: UL94 V-0
• Contact Finish-Post: tin
• Finish Thickness: 100.0µin (2.54µm)
• Contact Length-Post: 0.120" (3.05mm)
• Contact Length-Mating: 0.230" (5.84mm)
• Overall Contact Length: 0.440" (11.18mm)
• Insulation Height: 0.090" (2.29mm)
• Shrouding: unshrouded
• Row Spacing-Mating: 0.100" (2.54mm)
• Standard Package: 320
