6-146130-1

Part No 6-146130-1
Manufacturer TE Connectivity
Catalog Rectangular Connectors
Description CONN HEADER SMD 24POS 2.54MM / Connector Header Surface Mount 24 position 0.100" (2.54mm)
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects - Rectangular Connectors - Headers, Male Pins
Mfr TE Connectivity
Series AMPMODU Mod II
Package Tube
Product Status Active
Connector Type Header, Breakaway
Contact Type Male Pin
Pitch - Mating 0.100" (2.54mm)
Number of Positions 24
Number of Rows 2
Row Spacing - Mating 0.100" (2.54mm)
Number of Positions Loaded All
Style Board to Board or Cable
Shrouding Unshrouded
Mounting Type Surface Mount
Termination Solder
Fastening Type Push-Pull
Contact Length - Mating 0.230" (5.84mm)
Insulation Height 0.090" (2.29mm)
Contact Shape Square
Contact Finish - Mating Gold
Contact Finish Thickness - Mating 30.0µin (0.76µm)
Contact Finish - Post Tin
Contact Material Copper Alloy
Insulation Material Liquid Crystal Polymer (LCP)
Temperature Range - Operating -65°C ~ 125°C
Material Flammability Rating UL94 V-0
Insulation Color Black
Current Rating (Amps) 3A
Voltage Rating 30VAC
Contact Finish Thickness - Post 100.0µin (2.54µm)
Base Product Number 146130
Standard Package 17 pcs
MSL Level 1 (Unlimited)
REACH Status Vendor Undefined
ECCN EAR99
HTSUS 8536.69.4040
Win Source Part Number 856851-6-146130-1
Ultra Librarian 3D Model Ultra Librarian 6-146130-1 CAD Model

Description

The 856851-6-146130-1 is a male pin header connector from TE Connectivity. TE Connectivity manufactures this.

  • Connector Type: Header, Male Pin
  • Series: AMPMODU Mod II
  • Number of Positions: 24
  • Design: Breakaway Header
  • Termination Type: Solder
  • Fastening Type: Push-Pull
  • Package: Tube
  • Standard Package Quantity: 17 pieces
  • Contact Material: Copper Alloy
  • Voltage Rating: 30VAC
  • Flammability Rating: UL94 V-0
  • Connection Type: Board to Board or Cable
  • Mating Pitch: 0.100" (2.54mm)
  • Mating Contact Finish: Gold
  • Mating Contact Finish Thickness: 30.0µin (0.76µm)
  • Post Contact Finish: Tin
  • Post Contact Finish Thickness: 100.0µin (2.54µm)
  • Color: Black
  • Mounting Type: Surface Mount
  • Mating Row Spacing: 0.100" (2.54mm)
  • Operating Temperature: -65°C to 125°C
  • MSL Level: 1 (Unlimited)
  • Current Rating: 3A
  • REACH Status: Undefined by Vendor
  • HTSUS Code: 8536.69.4040
  • Base Product Number: 146130
  • Product Status: Active
