8-1415536-7 Real Image
Same model may have multiple batches, images only for reference.

8-1415536-7

Part No 8-1415536-7
Manufacturer TE Connectivity
Catalog Power Relays, Over 2 Amps
Description General Purpose Relays PCB Relays | RELAY GEN PURPOSE SPST 16A 12V
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Relays
Manufacturer TE Connectivity AMP Connectors
Packaging Bulk
Mounting Style Through Hole
Coil Voltage 12VDC
Contact Form SPST-NO (DM) (1 Form X)
Contact Rating (Current) 16A
Switching Voltage 400VAC - Max
Coil Current 30.0mA
Coil Type Non Latching
Termination Style PC Pin, Quick Connect - 0.250" (6.3mm)
Must Operate Voltage 7.9 VDC
Must Release Voltage 0.9 VDC
Temperature Range - Operating -20°C ~ 85°C
Contact Material Silver Nickel (AgNi)
Relay Type General Purpose
Coil Resistance 400 Ohms
Manufacturer Pack Quantity 300
MSL Level Not Applicable
Win Source Part Number 729240-8-1415536-7
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian 8-1415536-7 CAD Model

Description

The TE Connectivity AMP Connectors 8-1415536-7 is a relay electronic component that comes under the category of relays.

  • Termination Style: PC Pin, Quick Connect - 0.250" (6.3mm)
  • Mounting Style: Through-hole
  • Contact Form: SPST-NO (DM) (1 Form X)
  • Contact Material: Silver nickel (AgNi)
  • Coil Resistance: 400 Ohms
  • Coil Current: 30.0mA
  • Relay Type: General purpose
  • Coil Type: Non-latching
  • Coil Voltage: 12VDC
  • Contact Rating (Current): 16A
  • Switching Voltage: 400VAC - Max
  • Temperature Range - Operating: -20°C ~ 85°C
  • Supply and Demand Status: Limited
